93
C.2.4 DIAGNOSTIC INFORMATION
— Receiver Diagnostic Codes
— Signal Strength
— Error Code
— Error Description
— Device Serial Number
An Electronic Data Sheet (EDS) is supplied with each controller to assist in device configuration.
Table C-1 Specifications for 4700 System Controller with DeviceNet
(See main 4700 system manual for additional system specifications)
DeviceNet Power 24 VDC, 50 mA - Supplied by deviceNet BUS Network
DeviceNet
Configuration
Vendor Code: 405 (Scientific Technologies Inc.)
Device Type: 130 (Safety Light curtain)
Product Code: 6 (4700 series)
Connection Type Supported: Explicit Messages, Poll, Strobe, Change of State
MAC ID: 0-63 (network confirmed, 63 is default)
Baud Rate Supported: 125K, 250K, 500K (net
work
configured, 125K is default)
EDS File Name: 4700.eds
Bit Map Icon File Name: 4700.bmp, 4700.ico
EDS and Bitmap files supplied on 3-1/2” disk
Poll, Bit Strobe
and COS I/
O
Assembly
Instances
4700 device I/O assemblies consist of:
—Poll and Bit Strobe: Product specific input assembly containing operating
mode detection zone
status, safety output status, MTS and Remote Start
input status, Exact Channel Select and Floating Blanking switch settings.
—COS: Product specific input assembly containing operating mode.
