• Response Time for MCF4700, MCJ4700 and MSF4700
The MCF and MCJ can have up to four segments. It is possible for each segment to have a different
minimum object resolution.
Step 1: Determine the number of beams in each segment using Table 14-1, Table 14-2 and Table 14-
3.**
Step 2: Use the formula below to determine response time:
(Total number of beams x 0.0924) + 5.21 msec = response time in msec.
**The total number of beams in a system cannot exceed 192.
MCF4700 example:
MCF47-12200-301800-20300
The unit has three segments, a 12 mm resolution of 200 mm length, a 30 mm resolution of 1800 length
and a 20
mm resolution
of 300 mm length.
Table 14-1 show 32 beams for the 12 mm segment, Table 14-3 show 84 beams for the 30 mm segment
and Table 14-2 shows 28 beams for the 20 mm segment. The total number of beams is:
32 + 84 + 28 = 144.
From the formula:
(144 beams x 0.0924) + 5.21 ms = 18.5 ms.
