MCF47-30-1200-(X1, X2, or X3) MicroSafe Flexible MCF4700-30 Transmitter, 1209 mm (47.6 in.)
MCF47-30-1350-(X1, X2, or X3) MicroSafe Flexible MCF4700-30 Transmitter, 1359 mm (53.3 in.)
MCF47-30-1500-(X1, X2, or X3) MicroSafe Flexible MCF4700-30 Transmitter, 1509 mm (59.4 in.)
MCF47-30-1650-(X1, X2, or X3) MicroSafe Flexible MCF4700-30 Transmitter, 1659 mm (65.3 in.)
MCF47-30-1800-(X1, X2, or X3) MicroSafe Flexible MCF4700-30 Transmitter, 1809 mm (71.2 in.)
MCF4700-30 Receivers - First (R1), Mid (R2) and Last (X3) Segments
Model NumberDescription
MCF47-30-150-(R1, R2, or R3) MicroSafe Flexible MCF4700-30 Receiver, 159 mm (6.3 in.)
MCF47-30-300-(R1, R2, or R3) MicroSafe Flexible MCF4700-30 Receiver
, 309 mm (12.2 in.)
MCF47-30-450-(R1, R2, or R3) MicroSafe Flexible MCF4700-30 Receiver
, 459 mm (18.1 in.)
MCF47-30-600-(R1, R2, or R3) MicroSafe Flexible MCF4700-30 Receiver
, 609 mm (24.0 in.)
MCF47-30-750-(R1, R2, or R3) MicroSafe Flexible MCF4700-30 Receiver
, 759 mm (29.9 in.)
MCF47-30-900-(R1, R2, or R3) MicroSafe Flexible MCF4700-30 Receiver
, 909 mm (35.8 in.)
MCF47-30-1050-(R1, R2, or R3) MicroSafe Flexible MCF4700-30 Receiver
, 1059 mm (41.7 in.)
MCF47-30-1200-(R1, R2, or R3) MicroSafe Flexible MCF4700-30 Receiver
, 1209 mm (47.6 in.)
MCF47-30-1350-(R1, R2, or R3) MicroSafe Flexible MCF4700-30 Receiver
, 1359 mm (53.3 in.)
MCF47-30-1500-(R1, R2, or R3) MicroSafe Flexible MCF4700-30 Receiver
, 1509 mm (59.4 in.)
MCF47-30-1650-(R1, R2, or R3) MicroSafe Flexible MCF4700-30 Receiver
, 1659 mm (65.3 in.)
MCF47-30-1800-(R1, R2, or R3) MicroSafe Flexible MCF4700-30 Receiver
, 1809 mm (71.2 in.)
MCF4700-20 Receivers - First (R1), Mid (R2) and Last (R3) Segments
Model NumberDescription
MCF47-20-075-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 78 mm (3.1 in.)
Mid and Last Segments Only
MCF47-20-150-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 159 mm (6.3 in.)
MCF47-20-225-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 235 mm (9.3 in.)
MCF47-20-300-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 309
mm (12.2 in.)
MCF47-20-375-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 385
mm (15.2 in.)
MCF47-20-450-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 459
mm (18.1 in.)
MCF47-20-525-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 535
mm (21.1 in.)
MCF47-20-600-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 609
mm (24.0 in.)
MCF47-20-675-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 685
mm (27.0 in.)
MCF47-20-750-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 759
mm (29.9 in.)
MCF47-20-825-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 835
mm (32.9 in.)
MCF47-20-900-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 909
mm (35.8 in.)
MCF47-20-975-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 985
mm (38.8 in.)
MCF47-20-1050-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 105
9 mm (41.7 in.)
MCF47-20-1125-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 1135 mm (44.7 in.)
MCF47-20-1200-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 120
9 mm (47.6 in.)
MCF47-20-1275-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 128
5 mm (50.6 in.)
MCF47-20-1350-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 135
9 mm (53.3 in.)
MCF47-20-1425-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 143
5 mm (56.5 in.)
MCF47-20-1500-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 150
9 mm (59.4 in.)
MCF47-20-1575-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 158
5 mm (62.4 in.)
MCF47-20-1650-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 165
9 mm (65.3 in.)
MCF47-20-1725-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 173
5 mm (68.3 in.)
MCF47-20-1800-(R1, R2, or R3) MicroSafe Flexible MCF4700-20 Receiver, 180
9 mm (71.2 in.)
MCF4700-30 Transmitters - First (X1), Mid (X2) and Last (X3) Segments
