Chapter 2
2-81
Standard Models and Specifications
■ Position Control Unit Cables (XW2Z-@J-A8)
These Position Control Unit Cables connect a CS1W-NC113 or C200HW-NC113 Position Control
Unit and an XW2B-20J6-1B Servo Relay Unit.
● Cable Models
● Connection Configuration and External Dimensions
● Wiring
Model Length (L) Outer diameter of sheath Weight
XW2Z-050J-A8 50 cm 8.0 dia. Approx. 0.1 kg
XW2Z-100J-A8 1 m Approx. 0.1 kg
Position Control Unit
CS1W-NC113
C200HW-NC113
Servo Relay Unit
XW2B-20J6-1B
38
L 647
83
t=11
Position Control Unit
Cable: AWG28 × 4P + AWG28 × 9C
Servo Relay Unit
Crimp terminal
No.
A1
A2
A8
A6
A10
A24
A12
A21
A23
A22
A19
A20
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
25
26
24
A15
A14
To Next Page
