Omron SMARTSTEP R7D-AP Series - Communications Cables (XW2 Z-@J-C1)

Chapter 2
2-110
Standard Models and Specifications
■ Communications Cables (XW2Z-@J-C1)
These Communications Cables connect the communications port of an XW2B-40J6-4A Servo Relay
Unit that supports communications and a Programmable Controller Serial Communications Unit or
Board.
● Cable Models
● Connection Configuration and External Dimensions
● Wiring
Model Length (L) Outer diameter of sheath Weight
XW2Z-100J-C1 1 m 10.0 dia. Approx. 0.1 kg
XW2Z-200J-C1 2 m Approx. 0.2 kg
39 L
32.2
t=15
39
t=15
32.2
Symbol No. SymbolNo.
Shell
2
1
8
6
Shell
SDB
SDA
RDB
RDA
FG FG
Connector:
XM2A-0901 (OMRON)
Connector Hood:
XM2S-0911 (OMRON)
2
1
8
6
SDB
SDA
RDB
RDA
Connector:
XM2A-0901 (OMRON)
Connector Hood
XM2S-0911 (OMRON)
Cable: AWG28×2P UL2464
