Omron SMARTSTEP R7D-AP Series User Manual

Chapter 3
3-16
System Design and Installation
■ Terminal Block Wire Sizes
● 100-V AC Input (R7D-AP@L)
Note 1. Use the same wire sizes for 1, 2, B1, and B2.
Note 2. Connect an OMRON Servomotor Cable to the Servomotor connection terminals.
Item Model
Unit
R7D-APA3L R7D-APA5L R7D-AP01L R7D-AP02L R7D-AP04L
Power supply capacity kVA 0.2 0.25 0.4 0.75 1.2
Main circuit
power supply
input (L1, L2)
(See note 1.)
Effective
current
A (rms) 1.64 2.2 4.0 6.8 11
Wire size
mm
2
1.25 1.25 1.25 2 2
Control circuit
power supply
input (L1C,
L2C)
Effective
current
A (rms)0.130.130.130.130.13
Wire size
mm
2
1.25 1.25 1.25 1.25 1.25
Effective
current
A (rms) 0.42 0.6 0.89 2.0 2.6
Wire size
mm
2
1.25 1.25 1.25 1.25 1.25
Wire size
mm
2
22222
Screw
size
–M4M4M4M4M4
Tor q ue N
⋅m 1.2 1.2 1.2 1.2 1.2
No-fuse breaker or fuse
capacity
A (rms) 8 8 8 10 13
Servomotor
connection ter-
minal (U, V, W,
)
(See note 2.)
Frame ground
( )
+ +
