Chapter 2
2-84
Standard Models and Specifications
■ Position Control Unit Cables (XW2Z-@J-A12)
These Position Control Unit Cables connect a CS1W-NC133 Position Control Unit and an XW2B-
20J6-1B Servo Relay Unit.
● Cable Models
● Connection Configuration and External Dimensions
● Wiring
Model Length (L) Outer diameter of sheath Weight
XW2Z-050J-A12 50 cm 10.0 dia. Approx. 0.1 kg
XW2Z-100J-A12 1 m Approx. 0.2 kg
Position Control Unit
CS1W-NC133
Servo Relay Unit
XW2B-20J6-1B
48
L 647
83
t=11
1000
Servo Relay Unit
Cable: AWG28 × 4P + AWG28 × 9C
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
No.
Position Control Unit
A1
A2
A7
A8
A5
A6
A10
A24
A12
A21
A23
A15
A14
Crimp terminal
25
26
A20
A19
A22
A3
A4
AWG20 Black
AWG20 Red
To Next Page
