Omron SMARTSTEP R7D-AP Series User Manual

Chapter 3
3-32
System Design and Installation
Dimensions
(The dimensions given below are for noise filters with lead-wire terminals. For the dimensions of
noise filters with different types of terminals, contact the manufacturer.)
For single-phase input (FN2070-6/07, FN2070-10/07)
For single-phase input (FN2070-16/07)
Model A B C
FN2070-6/07 94 mm 103 mm 113.6 mm
FN2070-10/07 130.5 mm 143 mm 156 mm
45.4
56
57.5
18
0.9
8.4
140
+5
0
140
+5
0
A
B
C
6
4.4
57.6
140
+5
0
1.2
8.6
84.5 85.5
140
+5
0
98.5
51 66
4.4
109
119
7.4
