Chapter 2
2-7
Standard Models and Specifications
■ Single-phase 100 V AC: R7D-AP04L (400 W)
Single-phase 200 V AC: R7D-AP04H (400 W)
● Wall Mounting
● Front Panel Mounting (Using Mounting Brackets)
External dimensions
Mounted dimensions
160
149.5 5.5(5)
5 dia.
5
12
75
(75) 130
17
Two, M4
149.5±0.5
160
5.5
(5)
75
12
External dimensions
Mounted dimensions
24.5
2
5 dia.
(7.5)
5
11.542
180 195
7.5
32.5
180±0.5
195
7.5(7.5)
Two, M4
10
52 1.5
(168) 66
