3-6 Touch Panel Monitor and Cable
3
Use the USB cable for the connection cable of Touch Panel Monitor.
Use RS-232C cable for the connection cable of T
ouch Panel Monitor in the following cases.
• When the distance Touch Panel Monitor and FH Sensor Controller is 5 m or more.
• Cannot use the Touch Panel cable because the USB p
ort of FH Sensor Controller is used for the
other I/O connection.
Touch Panel Monitor Cables
Touch Panel Cable
Model FH-VMDA (2 m) FH-VUAB (2 m) XW2Z-200PP-1 (2 m)
Cable type DVI-Analog Conversion
Cabl
e
USB Cable RS-232C Cable
Vibration resis-
tance
10 to 150 Hz, one-side amplitude 0.1 mm, 10 times for 8 minutes for each three direction
Ambient Tem-
perature
Operating Condition: 0 to 50°C,
Storage Condition: -10 to 60°C (with no icing or condensation)
Ambient Humid-
ity
Operating and Storage Condition: 35 to 85%RH
(with no icing or condensation)
Ambient environ-
ment
No corrosive gases
Material Cable outer sheath, Connector: PVC Cable outer sheath: PVC,
Connector: ABS/Ni Plating
Minimum bend
radi
us
36 mm 25 mm 59 mm
Weight Approx.220 g Approx.75 g Approx.162 g
