OpenEye OE3-E48016 - Specifications OE3-E240 (H.264)

100
SPECIFICATIONS OE3-E240 (H.264)
Video
Inputs
• 4/8/16 Channel Composite
Outputs
• CCTV Monitor (NTSC/PAL)
• (VGA) Monitor
• 16 CH Looping Composite
• CCTV Spot Monitor (NTSC/PAL)
Monitoring
Display
• NTSC : 480 fps
• PAL : 400 fps
Screen split
• 1/4/9/16/PIP
Recording
Performance
• NTSC: 2CIF(240 ips), 4CIF (120 ips), 8CIF (60 ips)
• PAL: 2CIF (200 ips), 4CIF(100 ips), 8CIF (60 ips)
Resolution
• NTSC: CIF(352x240), 2CIF(704x240), 4CIF (704x480)
• PAL: CIF(352x288), 2CIF (704x288), 4CIF(704x576)
Compression
• H.264
Mode
• Motion detection, Sensor, Continuous, Schedules
• Variable compression rates, recording frame, motion sensitivity
Recording
Storage media
• Internal 2 x HDD (Option) • USB
Audio
• 4 Channel, G.726 Compression
Playback
Mode
• Multi-channel playback (Max 16ch), Simultaneous playback
Searching
• By Channel, Time, Date, Motion Detection, Sensor Events
Remote Monitoring S/W
• Remote Software / Web based viewer
Alarm
• 4
Sensor
• 16
Camera Control
• Pan/Tilt, Zoom, Focus, Iris
Back-up
• DVD+/-RW • USB
Temperature
• Operating: 0°C to 40°C (32°F to 104°F)
• Storage: 0°C to 40°C (32°F to 104°F)
Relative Humidity
• 0% ~ 90%, non-condensing
Hardware
Spec.
Size
• 15.75" (W) x 3.46" (H) x 15.75" (D) (400 mm x 88 mm x 400 mm)
Weight
• 8 lb (8.2 kg) W/O Packing
Power
• Input Voltage is 110-230V ~ 47/63Hz 1.75-.85A
UPS
• External UPS recommended
