Opticon
H15
User Manual
2-12
Table 2-2. Terminal overview
Label Description
1 Barcode reader LED
indicator
Red color: Barcode reader on
Green color: Successful reading
2 Charge LED indicator Red color: Charging battery
Green color: Battery fully charged
3 LCM / touch panel User input on touch panel by stylus
4 Scan key
Start scanning barcodes by pressing
Navigation/scan keys
5 Power key Put the Terminal into suspend mode
Awake the Terminal from suspend mode
6 F1 ~ F4 key Application keys, hot keys of application program
defined by end user.
7 Navigation key
Navigation keys for left, right, up and down
directions
8 Alpha-Numeric keys Numeric keys, change to alpha keys
9 Alpha key Toggle alpha-mode for alpha-numeric keys
10 Fn key This key is used in combination with other keys to
type special characters and perform system
functions.
11 Enter key This key confirms data entry
12 USB/Cradle
Synchronization Port
A connector to support DC-IN and USB Client.
connect to PC by ActiveSync with Cradle
13 Scan window Barcode reader window
14 Stylus
Use the stylus for selecting items and entering
information.
15 Battery Cover Protect battery pack and remain IP54 rating
16 Battery Cover Latch To keep battery cover locked
17 Speaker 1W speaker for audio output
