Oracle e-series User Manual

1-12 Introduction of the MICROS Tablet and Base Station E-Series
Specification Parameters
Magnetic Card
Reader
Optional POS Sleeve with Modular Integrated 3-Track MCR capable of
encryption at the swipe
Scanner Not Available
External
Connectors and
Controls with MSR
Sleeve
 Micro USB (charging only)
 Headphone/Microphone jack
 Volume Up/Down
 Power/Standby Button
 Gang Charger Pins
 Multi-function Docking Connector for Base Station
Network/Wireless  802.11 a/b/g/n WiFi with WPA WPA2, TKIP, AES support
 Bluetooth V4.00
Card Reader Micro-SD (SD, SDHC, SDXC - 64GB max)
Battery 2-Cell Lithium-Ion 32 Wh
Operating
Temperature
0°C (32°F) to 40°C (104°F)
Weight 726g (1.7lb)
Dimensions Length: 280mm (11.02 inches)
Width: 177mm (6.97 inches)
Thickness: 10.2 mm (0.40 inches)
Certifications
http://www.dell.com/regulatory_compliance_datasheets
Tablet E-Series 8 General Specifications
The Tablet E-Series 8 with MSR sleeve specifications are listed below.
Table 1-3 Tablet E-Series 8 General Specifications
Specification Parameters
Processor Intel Atom Z3740D Quad Core SoC @ 1.33 GHz (1.83 GHz Turbo)
2M L2 Cache
Intel Gen7 Integrated Graphics
Memory 2GB LPDDR3 SDRAM PC-1333
Storage 32 GB eMMC
Operating System Microsoft Windows Embedded 8.1 Industry Pro
(32bits)
Display 8.0” IPS Display at 1280x800
Portrait or Landscape orientation, Auto Rotating
Touchscreen 10-Point Capacitive Touch Sensor (supports multi-touch and gesturing)
