Introduction of the MICROS Tablet and Base Station E-Series 1-15
Port or Connector Power Bus Available Power
Multi-function Connector
to Tablet
VCC19.5 19.5V @ 2.0A (6.25W when
charging the Tablet -
Typical)
Cash Drawer VCC24
VCC12
24V @ 0.021A (0.5W)
12V @ 0.042A (0.5W)
The Base Station E-Series has five primary power busses, each with a fixed amount of
power available. VCC5, VCC9, and VCC12 are available at the I/O Panel for peripheral
devices.
VCC24 @ 2A is used only if Base Station E-Series 11 is configured to use 24V Cash
Drawers. It is not used to power peripheral devices.
VCC19.5 @ 2A is fed through the multi-function connector to power the Tablet E-
Series 11 and charge the internal battery. It is not used to power peripherals.
VCC12 @ 3.5A is available at COM1, COM2, USB 5, and the 12V Out Jack. A total
of 42 Watts is available. Each output can provide 1.5A or 18 Watts.
VCC9 @ 2A is available at the COM1 connector for use with some small form
factor printers. A total of 13.5 Watts is available.
VCC5 @ 4A is available at COM1, USB ports 1 through 5 and one or two customer
displays. A total of 20 Watts is available. See below.
Examples:
A MICROS Protégé Customer Display is connected to USB 5. It consumes 12
Watts from VCC12 and 2.5 Watts from VCC5. This leaves approximately 30 Watts
available on VCC12 and 17.5 Watts available on VCC5 for the I/O Panel USB
Ports and Customer Display(s).
A thermal printer such as the MICROS Integrated Mini-Printer consumes 15
Watts from VCC12, leaving 24 Watts available for other 12V devices. COM2 is the
recommended port for the Integrated Mini Printer.
Certifications
The Tablet and Base Station meet the following safety and environmental certifications.
Table 1-6 Tablet E-Series Safety and Environmental Certifications
Directive Specification Year
Safety EN 60950-1:2006+A11+A1+A12 2011
(2006/95/EC) IEC 60950-1:2005+A1 2010
R&TTE EN 300 328 V1.8.1 2012
(1999/5/EC) EN 301 489 V1.9.2 2011
EN 301 489-17 V2.2.1 2012
