Introduction of the MICROS Tablet and Base Station E-Series 1-13
Specification Parameters
Magnetic Card
Reader
Optional POS Sleeve with Modular Integrated 3-Track MCR capable of
encryption at the swipe
Scanner Optional POS Sleeve supports 1D/2D Imager/Scanner
External
Connectors and
Controls with MSR
Sleeve
 Micro USB (charging only)
 Headphone/Microphone jack
 Volume Up/Down
 Power/Standby Button
 Gang Charger Pins
 Scanner Trigger Button (Optional Scanner)
Network/Wireless  802.11 a/b/g/n WiFi with WPA WPA2, TKIP, AES support
 Bluetooth V4.00
Card Reader Micro-SD (SD, SDHC, SDXC - 64GB max)
Battery 2-Cell Lithium-Ion 18 Wh
Operating
Temperature
0°C (32°F) to 35°C (95°F)
Weight 400g (0.88lb)
Dimensions Length: 216mm (8.51 inches)
Width: 130mm (5.11 inches)
Thickness: 9 mm (0.35 inches)
Certifications
http://www.dell.com/regulatory_compliance_datasheets
Base Station E-Series General Specifications
The Base Station E-Series is designed specifically for the Tablet E-Series 11. It is not
compatible with Tablet E-Series 8 or the MCIROS Tablet R-Series.
Table 1-4 Base Station E-Series General Specifications
Specification Parameters
Processor NXP LPC1751
Memory On-Board 32K Flash, 8K SRAM
LAN Interface 10/100/1000 Mb LAN /w RJ-45 Connector
Serial Ports 2 DB9 Powered RS232 Serial with handshake
• COM1 - user selectable 5V/9V/12 options
• COM2 - 12V available
1 Modular RS232 Serial /w handshake
1 Modular IDN Serial (RS422 or RS232) 
Refer to the Peripheral Power Specification table on
the next page.
