B-4 Appendix B

Pin Number Signal Name Description

3, 7, 8 Ground Signal Grounds

4 CD_ST Input Status from the Cash Drawer

5 MCU_TX_5V Tx data to Cash Drawer

6 MCU_RX Rx data from Cash Drawer
