Orban OPTIMOD 8685 User Manual

2-78
INSTALLATION ORBAN MODEL 8685
Use either an internal modem or external modem with your computer.
a) If you are using an external modem, connect the modem to a serial port on
your PC and make sure the modem is connected to a working phone line.
b) On your PC, click “Start > Settings > Control Panel > Phone and Modem
Options.”
c) Click the “Modems” tab.
d) Verify that your modem appears in the list available under “The following
Modems are installed.”
e) Verify that your modem is “Attached to” the correct port.
If your modem is unavailable or not attached to the correct port, you
must Add it. See your Windows documentation.
f) If your modem is available in the list available under “The following
Modems are installed” and it is attached to the correct port, then click
“Properties” for that modem.
g) Make sure the port speed is set at 115200.
h) Click “OK.”
B) Create a New Windows 2000 Dial-Up Connection:
a) Click “Start > Settings > Network and Dial-up Connections > Make New
Connection.”
b) Once the New Connection Wizard has opened, Click “Next.”
C) Create a New Windows 2000 Direct
Connection:
a) Launch 8685 PC Remote.
b) Choose “Connect > New 8685”
c) Give your 8685 a name (e.g.,
“KABC”) by entering this
name in the “8685 Alias”
field.
d) If you wish to have 8685 PC
Remote remember the
password for this Optimod,
enter the password in the
“Password“ field.
e) Select “Serial Connection.”
f) Click the “Add” button.
