OPTIMOD SURROUND PROCESSOR INSTALLATION
2-47
H) Set the port properties as follows:
Bits per second ..........9600
Data Bits.....................8
Parity .........................none
Stop bits .....................1
Flow control...............none
I) Choose OK.
J) L
OCATE to File > Properties > Settings > ASCII Setup. Set the ASCII Setup prop-
erties as follows:
Check:
Send line ends with line feeds
Echo typed characters locally
Wrap lines that exceed terminal width
Uncheck:
Append line feeds to incoming line ends
Force incoming data to 7 bit ASCII
Leave “Line delay” and “Character delay” at their default values.
K) Activate the C
APS LOCK on your computer to ensure that you type in upper-
case.
You can now type in commands described in the specification in
Administrative Operations below.
Administrative Operations
In the following tables of commands and responses:
Text that the user enters appears in MONOSPACED BOLD.
Responses that the 8685 transmits appear in monospaced normal.
The symbol “«” means CR (for received commands) and CR+LF (for transmit-
ted responses from 8685).
1. To recall a preset:
Command Response
RP XXXXXXX[PASSCODE]«
(valid passcode and preset name)
ON AIR: XXXXXXX
(invalid passcode)
[no error message is issued]
In the above table: XXXXXXX = the preset name;
PASSCODE = any valid passcode.
If a non-existent preset name, control value, and/or an invalid passcode is en-
