OPTIMOD SURROUND PROCESSOR TECHNICAL DATA
6-27
POWER SUPPLY DISTRIBUTION
PART # DESCRIPTION COMPONENT IDENTIFIER
30V5.6A
23417.000.01.1
Transistor MOSFET N-Channel
FDD6770A
Q1, Q2, Q5, Q6
24351.000.01.1 IC Voltage Regulator NEG 5V D2PAK U5
24350.000.01.1 IC Voltage Regulator POS 5V D2PAK U4
29555.126.01.1 Inductor 12UH 12A Toroid Vertical L1
27451.024.01.1 Header STR Double Row PC-Mount J5
27451.003.01.1 Header STR Double Row PC-Mount J3
27451.004.01.1 Header STR Double Row PC-Mount J4
27479.004.01.1 Connector Header .156CTR 4 PIN (J7 NO STUFF)
20130.309.01.1 Resistor 3.09K 1% 0805 R3, R6
20130.316.01.1 Resistor 31.6K 1% 0805 R1, R4
22084.167.01.1 Diode TVS 16.7V BIDIR CR3, CR4, CR5, CR8
21331.106.01.1 Capacitor Tantalum 10UF 35V SMD
C5, C10, C11, C22, C23, C24, C27,
C33
22084.064.01.1 Diode TVS 6.4V BIDIR CR1, CR2
23416.000.01.1
Transistor MOSFET N-CHANNEL 20V
î±±4.2
Q9
21139.000.01.1 Capacitor X7R 0.1UF 10% 0805
C1, C2, C3, C4, C7, C12, C13, C16,
C18, C19, C25, C26, C31, C34, C36,
C37, C38, C39, C40
20128.010.01.1 Resistor 10Ω 0805 R9, R10
20130.200.01.1 Resistor 2.00K 0805 R12, R13, R22, R24, R42, R44
22101.001.01.1 Diode 1N4148WT/R CR6, CR7, CR9, CR10
21318.510.01.1
Capacitor Tantalum 1.0uF 35V A-
CASE
C20
21171.105.01.1 Capacitor 1uf X7R 0805 C21
21146.310.01.1 Capacitor 0.01uf 0805 10% 0805 C9, C14, C15, C29, C30, C32, C35
20130.162.01.1 Resistor 1/8W 1% 1.62K 0805 R14
16024.000.01.1 Heatsink D2-PAK SMD HS_U4, HS_U5
Optional HD-SDI I/O Board
OPTIONAL HD-SDI I/O BOARD
PART # DESCRIPTION COMPONENT IDENTIFIER
32360.000.1 PCA HD-SDI DOLBY E I/O
32361.000.04.1 PCB HD-SDI DOLBY E I/O
20131.301.01.1 Resistor 30.1K 0805 R501
20129.210.01.1 Resistor 0805 210Ω 1% 1/8W R300, R309, R318, R621, R622
24789.000.01.1 IC INV 2-6V SGLE CMOS SOT U602, U605, U606, (U1400 NO STUFF)
20131.499.01.1 Resistor 1/8W 1% 49.9K 0805 R500
20131.140.01.1 Resistor 1/8W 1% 14.0K 0805 R214
