Orban OPTIMOD 8685 User Manual

OPTIMOD SURROUND PROCESSOR TECHNICAL DATA
6-17
BASE BOARD
PART # DESCRIPTION COMPONENT IDENTIFIER
24982.000.01 IC, 74HC4051M U19
24983.000.01 IC, 7064STC100-10 U1
24984.000.01 IC, LP2987IM-5.0 U20
25008.000.01 IC, PS2506-4 U10, 12
25112.001.01
LED, Red/Green, Bi-
Color/POLR
27017.025.01
Connector, Right Angle, PC
Board Mount, 25P
J10
27147.018.01 IC, Socket, DIP, 18 PIN, DUAL SU18
27223.002.01
Cable, Flat, 2 Long, 14 Conduc-
tor
J8
27371.040.01
Connector Header PC104
Stack 40P
Header2
27371.064.01
Connector Header PC104
Stack 64P
Header1, Header3
27406.014.01
Connector, Socket, Strip, 14
PIN
J2
27421.004.01
Connector, Header, Double
ROW, 4P, 2 X 2
J3B, J6
27421.006.01
Connector, Header, Double
ROW, 6P, 2 X 3
J5
27421.010.01
Connector, Header, Double
ROW, 23", 2 X 5
J12
27421.050.01
Connector Header STR .23
2x25
J9
27426.003.01
Connector, Header, 3 Pin, Sin-
gle Row
J11
27451.005.01
Connector, STR, Double Row,
26 PIN
J4
27451.024.01
Header, STR, Double Row, PC
MOUNT
J1
27500.000.01
Connector MOL53047-0510
5PIN
J14
28086.000.01 Crystal, 4.0 MHz, HC49US X1
29521.000.01 Inductor, 3.9uH, JM391K L1, L2, L3
32166.000.06 Circuit Board, Base Board
44093.100.01 Software PIC 8300 U18 U18
47010.016.01
Subassembly RECPTL-
W/SHRINK
J3A
47010.017.01
Subassembly RECPTL-
W/SHRINK
J3A
CPU Module
CPU MODULE
PART # DESCRIPTION COMPONENT, IDENTIFIER
20128.010.01 Resistor, 10Ω,0805 R31, R34
20128.022.01 Resistor, 22Ω 1% 0805 R5, R6
20128.332.01 Resistor, 33.2Ω,0805 R10, R11, R14
