OPTIMOD SURROUND PROCESSOR INSTALLATION
2-1
Section 2
Installation
Installing the 8685
Allow about 2 hours for installation.
Installation consists of: (1) unpacking and inspecting the 8685, (2) checking the line
voltage setting, fuse, and power cord, (3) mounting the 8685 in a rack, (4) connect-
ing inputs, outputs and power, (5) optional connecting of remote control leads and
(6) optional connecting of computer interface control leads.
When you have finished installing the 8685, proceed to “Quick Setup,” on page 2-8.
1. Unpack and inspect.
A) If you note obvious physical damage, contact the carrier immediately to make
a damage claim. Packed with the 8685 are:
Quantity Item
1 Operating Manual
2 Line Cords (domestic, European)
2 Fuses (½ A-250V Slow-Blow for 115V; 250 mA-250V for 230V)
2 Fuse holders (gray for 115V fuses and black for 230V fuses)
4 Rack-mounting screws, 10-32 x ¾—with washers, #10
1 Ethernet crossover cable
1 PC Remote Software CD
B) Save all packing materials! If you should ever have to ship the 8685 (e.g., for
servicing), it is best to ship it in the original carton with its packing materials
because both the carton and packing material have been carefully designed
to protect the unit.
C) Complete the Registration Card and return it to Orban. (please)
The Registration Card enables us to inform you of new applications, per-
formance improvements, software updates, and service aids that may be
developed, and it helps us respond promptly to claims under warranty
without our having to request a copy of your bill of sale or other proof
of purchase. Please fill in the Registration Card and send it to us today.
(The Registration Card is located after the cover page).
