2-56
INSTALLATION ORBAN MODEL 8685
End remote control interface programming.
When you are finished programming the remote control interface, press the
E
SCAPE button once to return to the System Setup screen.
Networking and Remote Control
This section describes how to connect a PC to your 8685 remotely for downloading
software upgrades and for PC Remote Control.
The 8685 has a built-in Ethernet connector that can be used with 10 Mbps or 100
Mbps networks using the TCP/IP protocol. You can also connect a PC to the 8685
through the 8685’s RS-232 serial port, either by modem or directly through a null
modem cable.
1. Prepare the 8685 for a network connection.
[Skip this step if you will not be using an Ethernet connection.]
A) Set the IP address:
a) From the main menu,
LOCATE to SYSTEM SETUP > NETWORK REMOTE >
NETWORK.
b) If you wish to change the IP Address, L
OCATE to SET ADDRESS. Press the
E
NTER button to access the SET IP ADDRESS screen.
192.168.254.254 is the 8685 default setting.
c) LOCATE to CLEAR, then press the ENTER button.
This will allow you to enter your IP address.
d) LOCATE to the first number and press the ENTER button; repeat until you
have selected all the numbers in the IP address assigned by your network
administrator. When the IP address entry is complete, L
OCATE to SAVE and
press the E
NTER button.
B) If necessary, set the Subnet Mask assigned by your network administrator:
a) L
OCATE to SET SUBNET.
Unless previously set away from the factory default, the Subnet Mask
should indicate 255.255.255.0.
b) Press the ENTER button to access the SET SUBNET MASK screen.
c) L
OCATE to the first number and press the ENTER button; repeat until you
have selected all the numbers in the Subnet Mask. When the Subnet Mask
entry is complete, toggle to S
AVE and press the ENTER button.
The 8685 will not accept an invalid Subnet Mask (like 255.255.255.300).
C) If necessary, set the Gateway assigned by your network administrator.
