Orban OPTIMOD 8685 - Encoder Board; LCD Carrier Board

OPTIMOD SURROUND PROCESSOR TECHNICAL DATA
6-25
HEADPHONE BOARD
PART # DESCRIPTION COMPONENT IDENTIFIER
21139.000.01
Capacitor, X7R, 0.1uF, 10%,
0805
C5, C6, C7, C8, C9, C10, C11, C12
21142.000.01
Capacitor, NPO, 100PF, 1%,
0805
C2, C4
21445.510.01
Capacitor, Metalized Polyester,
1.0uF, 50V, 5%
C1, C3
24025.000.01 IC, BUF634P, DIP8 U2, U3, U4
24960.000.01 IC, OPA2134UA U1
27090.000.01
Jack, Socket, 1/4" Phone, Right
Angle
J1
27147.008.01 IC, Socket, DIP, 8 PINS, DUAL SU2, SU3, SU4
27408.003.01 Connector, 3P Socket STRIP SL1, SL2, SL3
27758.006.01 Connector 6P Molex Right Angle J2
29508.210.01 Filter-EMI Suppression-50V- L1, L2, L3
32091.000.05 Circuit Board Headphone Board
57148.000.01 Bracket, Phone 8500 TYPE
Encoder Board
ENCODER BOARD
PART # DESCRIPTION COMPONENT IDENTIFIER
15061.003.01 LED MOUNT, T-1, 0.220 LEDMNT
21129.410.01
Capacitor, AXL LDS, 0.1uF, 50V,
20%
C1
25122.000.01 LED, T 1 3/4 RED/GRN LED 1
26088.000.01 Encoder, Rotary, Noble 8500 EN1
26128.000.01 Switch, Joymouse, Push, 8500 A1
26304.001.01 Switch, Push-Mom, SPST SW1, SW2
27421.016.01
Connector, Header, STR, .23", 2
X 8
JP1
32101.000.03 Circuit Board Encoder DPL/DEL
LCD Carrier Board
LCD CARRIER BOARD
PART # DESCRIPTION COMPONENT IDENTIFIER
11568.000.01
SCREW, THREAD-FORM
3x6MM
21112.282.01
Capacitor, Ceramic, 0.0082uF,
1KV, 10%
C1
22106.000.01 Diode, SMCJ26C, TRANZORB D3
22209.000.01 Diode, Shottky 1A, 60V, SMD D1, D2
24758.000.01 LCD Backlight Driver/CCFT A1
