Orban OPTIMOD 8685 User Manual

6-22
TECHNICAL DATA ORBAN MODEL 8685
DSP Board
DSP BOARD
PART # DESCRIPTION COMPONENT IDENTIFIER
20119.020.01.1
Resistor 0.02 Ω 1/4W 1% Sur-
face-Mount
(R701, R702, R712 NO STUFF)
32246.000.08.1 Circuit Board, DSP, 8500/8585
27451.002.01.1
Header STR Double Row PC-
Mount
J604
21305.610.01.1
Capacitor Radial Leads 10uF
20V 10%
C766
27468.006.01.1 Connector 6P MOLEX PC-Mount J200
21175.000.01.1
Capacitor 6800PF 10% X7R
0805
C101, C103, C105, C107, C109, C111, C113,
C115, C117, C119, C121, C123
24757.000.01.1 IC DSPB56367AG150 150MHZ
IC101, IC102, IC103, IC104, IC105, IC106,
IC107, IC108, IC109, IC110, IC111, IC112
16021.000.01.1
Heatsink, Vertical Mount, Black
Anodized
HS700, Use Compound
24944.000.01.1 IC EPM 7064AETC44-10 SMT IC503
21137.447.01.1 Capacitor .47uF 25V 10% 1206
C102, C104, C106, C108, C110, C112, C114,
C116, C118, C120, C122, C124
27451.007.01.1
Connector Double Row PC-
Mount 40 PIN
J504
27451.003.01.1
Header STR Double Row PC-
Mount
J701
27421.010.01.1
Connector Header Double Row
23" 2 X 5
J603
27421.002.01.1
Connector Header Double Row
2P 2 X 1
J500
24993.000.01.1 IC EPM7256AE24995TC100-10 IC603
24964.000.01.1 IC,LM2576T-3.3 FLOW LB03 IC700
24946.000.01.1 IC-8 Bit-Dual Transceiver W/3 IC502
20221.101.01.1
Resistor Network SIP 2% 100K
10PIN
R501
24948.000.01.1 IC 74LVC2244 DRVR20-SOIC IC601, IC602, IC604
27630.001.01.1 Jumper PC MNT TEST PT
TP702, TP200, TP201, (TP700, TP701,
TP703, TP704, NO, STUFF, )
42008.020.03.1 Subassembly Flat Cable 40P 2" J601, J602
24622.000.01.1 IC 74AHCT04 Invert SOIC IC807
21139.000.01.1 Capacitor X7R 0.1uF 10% 0805
C202, C203, C233, C234, C235, C500, C701,
C702, C703, C704, C705, C706, C707, C708,
C709, C710, C711, C712, C713, C714, C715,
C716, C718, C719, C720, C721, C723, C724,
C725, C726, C727, C728, C729, C730, C731,
C732, C733, C734, C739, C740, C741, C742,
C743, C744, C745, C746, C747, C748, C749,
C750, C751, C752, C753, C754, C755, C756,
C757, C758, C759, C760, C762, C786, C787,
C788, C789, C790, C791, C792, C793, C794,
C795, C796, C797, C798, C799, C800, C802,
C805, C809, C810, C811, C812, C813, C814,
C815, C816, C817, C818, C819, C820, C821,
C822, C823, C824, C825, C826, C827, C828,
C829, C830, C831, C832, C839
24549.000.01.1 IC SRAM 16MB TSSOP IC803, IC808, IC809
24945.000.01.1
IC 74AHC541 Octal Buffer
SOL20
IC501, IC504
