OPTIMOD SURROUND PROCESSOR TECHNICAL DATA
6-21
BASE INPUT/OUTPUT BOARD (no SDI)
PART # DESCRIPTION COMPONENT, IDENTIFIER
27406.014.01.1 Connector Socket Strip 14 pin JP600
21139.000.01.1 Capacitor X7R 0.1uF 10% 0805
C203, C204, C205, C206, C207, C208, C209,
C210, C211, C212, C213, C300, C301, C302,
C303, C304, C305, C306, C307, C308, C309,
C310, C311, C312, C313, C314, C400, C401,
C402, C403, C404, C405, C406, C407, C408,
C409, C410, C411, C412, C413, C414, C500,
C501, C502, C503, C601, C602, C603, C604,
C605, C606, C607, C608, C609, C610, C723,
C724, C725, C726, C727, C728, C729, C730,
C731, C732, C733, C734, C735, C736, C737,
C738, C739, C740, C741, C742, C743, C744,
C745, C746, C747, C748, C749, C750, C751,
C752, C753, C754, C755, C756, C757, C758,
C759, C760, C761, C762, C763
29015.000.01.1
AES3 Transformer Surface
Mount SCIENTI
T300, T301, T302, T303, T304, T305, T400,
T401, T402, T403, T404, T405
20135.002.01.1 Resistor 0805 5% 2ohm R700, R701, R702, R703, R704, R705
29532.000.01.1 Inductor Axial 560uH 370MA L600, L601
29537.102.01.1 Inductor 0805 Ferrite 1000 Ω
L700, L701, L702, L703, L704, L705, L706,
L707, L708, L709, L710, L711
20129.604.01.1 Resistor 0805 604 Ω 1% 1/8W R509
21177.000.01.1 Capacitor 0805 0.22uF X7R C505
29508.210.01.1 Filter EMI Suppression 100V 10 L200, L201, L202, L203
29506.001.01.1 Bead Ferrite On Wire
L300, L301, L302, L303, L304, L305, L306,
L307, L308, L309, L310, L311, L400, L401,
L402, L403, L404, L405, L406, L407, L408,
L409, L410, L411
27147.008.01.1 IC Socket DIP 8 Pin Dual SL204, SL205
27053.003.01.1
Connector Male Insert Right-
Angle
J200, J201
24997.000.01.1 IC DAC AK4393VSP VSOP IC200
24979.000.01.1 IC BAT54C-7 CR500, CR501
24960.000.01.1 IC OPA2134UA IC201, IC202, IC203
24958.000.01.1 IC DRV134PA IC204, IC205
24900.000.01.1 IC Hex Inverter SMT IC601
22106.000.01.1 Diode VSTT SMCJ26 DO214 CR200, CR201, CR202, CR203
21319.610.01.1 Capacitor 10uf Tantalum SMT C700, C701
21171.105.01.1 Capacitor 1uf X7R 0805 C200, C201, C202
21146.310.01.1 Capacitor 0.01uf 0805 10% C507, C764
21143.000.01.1
Capacitor NPO 1500PF 1%
0805
C218, C219, C504
20511.310.01.1 Trimpot 10K 10% 3/8TOP ADJ VR200, VR201
20133.100.01.1 Resistor 0805 1.0M 1% 1/8W R227, R228
20131.825.01.1 Resistor 1/8W 1% 82.5K 0805 R213, R214, R215, R216
20131.113.01.1 Resistor 0805 11.3K 1% 1/8W R223, R224, R225, R226
20131.100.01.1 Resistor 10K 0805
R200, R201, R202, R500, R501, R502, R503,
R504
20130.845.01.1 Resistor 1/8W 1% 8.45K 0805
R203, R204, R205, R206, R207, R208, R209,
R210, R211, R212
20130.348.01.1 Resistor 1/8W 1% 3.48K 0805 R217, R218, R219, R220, R221, R222
20130.100.01.1 Resistor 1.00K 1% 0805 R600, R601, R602, R603
24676.000.01.1 IC TRANS CS8427 28 PIN IC501
29535.000.01.1 Inductor 3.9uH CHIP 1008 L204, L205, L206, L207
