2-38
INSTALLATION ORBAN MODEL 8685
See step 6 on page 2-3 for wiring instructions.
You can program the two tally outputs independently to indicate a number of
different operational and fault conditions.
A) L
OCATE to SETUP > NETWORK REMOTE > TALLY OUTPUT > TALLY 1.
B) Program tally output #1.
To program a given tally output, L
OCATE to TALLY 1 or TALLY 2. As you
turn the control knob, the functions listed below will appear in the high-
lighted field.
• Channel xx Silent: Indicates that the level of the specified hardware input
channel has been below the S
ILENCE THRESHOLD for longer than the SILENCE
DELAY. See step (21.B) on page 2-37.
This function can detect if the center channel is silent.
• Surround Silent: Indicates that the levels at all hardware input channels
assigned to surround processing have been below the S
ILENCE THRESHOLD
for longer than the S
ILENCE DELAY.
• 2.0 (x) Silent: Indicates that the level at either logical input channel as-
signed to a given 2.0 processor (of which there are four available) has been
below the S
ILENCE THRESHOLD for longer than the SILENCE DELAY.
• AES xx In Error: Indicates that the AES input receiver chip on hardware
input xx has detected an unlock error, which can occur if there is no input
carrier or if the carrier is corrupted.
• SDI Error: Indicates that the signal applied to the HD-SDI input is unavail-
able or corrupted.
• Input Normal: Indicates that the silence sense function has not automati-
cally switched an input to its assigned fallback input.
• Input Fallback: Indicates that the silence sense function has automatically
switched an input to its assigned backup because it detected silence. See
step 21 on page 2-37.
• No Func
tion: Tally output is disabled.
C) Program tally output #2 if you wish, following the procedure in step (B) above
with the T
ALLY 2 field.
Using Clock-Based Automation
1. If you have not already done so, set the system clock.
If you can connect your 8685 to the Internet through the 8685’s Ethernet port,
you can specify an Internet timeserver to set your 8685’s clock automatically. In
addition, Optimod PC Remote software can automatically set your Optimod’s lo-
