OPTIMOD SURROUND PROCESSOR TECHNICAL DATA
6-19
CPU MODULE
PART # DESCRIPTION COMPONENT, IDENTIFIER
24972.520.01
IC Microprocessor ELANSC520
BGA388
U1
27306.000.01
Connector RJ45 PCMT
W/MAGS
J1
27370.040.01 Connector Socket PC104 40pin P2
27370.064.01 Connector Socket PC104 64pin P1, P3
28031.000.01 Holder, Battery, Lithium Cell BT1HLDR
28041.000.01 Cell,Coin,Battery,Lithium,3V BT1
28089.000.01
Oscillator 33MHZ SG636 4P
SMD
X1
28090.000.01 IC TCXO DS32KHZ 36P BGA U13
28091.000.01
Crystal 25MHZ RXD MP35L
SMD
Y1
32201.000.02 PCB Control Module 8500
44094.100.01 Firmware 8500 U6 20LV8D
Serial I/O Board
SERIAL I/O BOARD
PART # DESCRIPTION COMPONENT IDENTIFIER
27459.006.01.1
Header 1X6 .100 PC-Mount
W/LK
J6 (NO STUFF)
20129.110.01.1 Resistor 0805 110 Ω 1% 1/8W R3 (NO STUFF)
20128.000.01.1 Resistor 0 Ω 0805 R4 R5 (NO STUFF)
44121.000.01.1 Firmware IC PIC MCU U5
21325.610.01.1
Capacitor 10uF 10% Tantalum
3528
C13, C16, C20,
21139.000.01.1 Capacitor X7R 0.1uF 10% 0805
C1, C2, C3, C4, C5, C6, C7, C8, C9, C10,
C11, C12, C15, C17, C18, C19, C21, C22,
C23, C24, C25
20130.100.01.1 Resistor 1.00K 1% 0805 R1, R2, R11, R14, R15, R16, R17
20165.110.01.1 Resistor 110 Ω 1% 1210 R6, R7, R8, R9
24792.128.01.1 IC PIC24FJ128GA106 MCU U5
24343.000.01.1 IC TPS76933DBVR LDO REG U6
27459.005.01.1
Header 1X5 .100 PC-Mount with
Lock
J5
24623.000.01.1 IC Octal Buffer/Line Driver 20 U7
25102.000.01.1 LED Yellow WATER CLR 1206 D3
20129.475.01.1 Resistor 475 Ω 1% 1/8W 0805 R18
23214.000.01.1 Transistor NPN MMBT3904 Q1, Q2
20237.472.01.1 Resistor Network 8R ISO 5% RN1
20131.100.01.1 Resistor 10K 0805 R10, R12, R13
32336.000.02.1 Circuit Board RS-232/485 Board
27147.014.01.1 IC Socket,DIP,14 Pin ,Dual SU2, SU3
27018.009.01.1 Connector, DB9, Female, Filter J2, J3
24966.000.01.1 IC, QUAD UART, ST16C554DC U4
27147.124.01.1 IC Socket DIP 24 pin Dual SU1
27017.009.01.1
Connector Right-Angle PC-Mount
9P MAL
J1
