Orban OPTIMOD 8685 User Manual

6-18
TECHNICAL DATA ORBAN MODEL 8685
CPU MODULE
PART # DESCRIPTION COMPONENT, IDENTIFIER
20128.499.01 Resistor, 49.9Ω 1% 0805 R19, R20, R21, R22, R23
20129.160.01 Resistor, 160Ω 1% 0805 R24, R25
20129.330.01 Resistor, 330Ω 1% 0805 R12, R16
20129.470.01 Resistor, 470Ω 1% 0805 R13, R15
20130.100.01 Resistor, 1.00K 1% 0805 R17, R35
20130.475.01 Resistor, 4.75KΩ,0805
R3, R4, R7, R8, R26, R27, R28, R29, R30,
R32
20130.931.01 Resistor, 9.31KΩ, 1%, 0805 R33
20131.100.01 Resistor, 10KΩ,0805 R1, R2, R9
20131.147.01
Resistor,
1/8W,1%,14.7KΩ,0805
R18
20233.102.01
Resistor Network 1K CTS745C
8R BUSSED
RN1
20233.472.01
Resistor Network 4.7K
CTS745C 8R BUSS
RN2, RN3, RN4
20237.472.01 Resistor Network 8R, ISO, 5% RN5
21139.000.01
Capacitor,
X7R,0.1uF,10%,0805
C8, C9, C20, C21, C177, C179, C182
21141.000.01
Capacitor,
NPO,1000pF,1%,0805
C10
21142.000.01
Capacitor,
NPO,100pF,1%,0805
C2
21146.310.01 Capacitor, .01uF,0805,10%
C11, 126, 127, 133, 134, 150, 152, 154,
156, 158,160, 162, 180
21167.047.01 Capacitor, 4.7pF 50V X7R 0805 C1
21170.018.01
Capacitor, 18pF 1% 50V COG
0805
C3, C4, C5, C6, C7
21171.105.01 Capacitor, 1uF X7R 0805
C14, 17, 125, 132, 151, 153, 155, 157, 159,
161, 175, 176, 178, 181, 183
21322.547.01
Capacitor,
4.7uF,Tantalum,6032B
C12
21325.610.01
Capacitor, 10uF 10% Tantalum
6032-B
C13, C15, C16, C18
22101.001.01 Diode,1N4148WT/R D1, D2, D3
24331.025.01
IC Voltage Regulator LT1963-
2.5 SOT223
U14
24331.033.01
IC Voltage Regulator LT1963-
3.3 SOT223
U15
24541.000.01
IC SDRAM MT48LC16
TSOP54P
U2, U3
24542.000.01
IC Flash Memory E28F128
TSOP56
U4
24543.000.01 IC CY2305 0 Delay Buffer 8P U11
24544.000.01
IC NM93C46 Static EEPROM
TSSOP
U12
24653.000.01 IC PWRST MIC8114 SOT143 U5
24670.000.01 IC 10/100BT NIC NATIONAL U10
24965.000.01 IC,74ALVC164245DGG U7, U8, U9
