OPTIMOD SURROUND PROCESSOR TECHNICAL DATA
6-23
DSP BOARD
PART # DESCRIPTION COMPONENT IDENTIFIER
20128.332.01.1 Resistor 33.2 Ω 0805 1% 1/8W R615
20130.499.01.1 Resistor R0805 4.99K 1% 1/8W R100, R510, R705
20130.200.01.1 Resistor 2.00K 0805 R707, R708, R709, R710
29527.000.01.1
Inductor, Toroidal 8.06uH FIT44-
4
L701
29512.000.01.1 Choke Shield 1670-1 250UH L702
28083.000.01.1
Oscillator, Crystal Clock-27MHZ
3V
IC804
20128.000.01.1 Resistor 0 Ω 0805 (R714, R715, R716, R717, R718 NO STUFF)
22104.000.01.1 Diode SCHOT Rectifier 1N5818 CR706, CR707
22208.040.01.1 Diode-Shottky-31DQ04-3 CR701
24333.000.01.1 IC-ST23-LM4041-ADJ IC702
24334.000.01.1 IC LT1767 MS8E 1.8V 1.5A IC701
29537.102.01.1 Inductor 0805 Ferrite 1000 Ω L800, L801, L802
29504.150.01.1 Inductor 2A PE53113 L700
24997.000.01.1 IC DAC AK4393VSP VSOP IC211
24960.000.01.1 IC OPA2134UA IC201
24938.000.01.1 IC Single 2 Input SMT IC810, IC811
23214.000.01.1 Transistor NPN MMBT3904 Q700
22101.001.01.1 Diode 1N4148WT/R CR704, CR705
22083.068.01.1 Diode Voltage Suppressor 6.8 V CR702
22083.033.01.1 Diode Voltage Suppressor 33 V CR700
21319.610.01.1 Capacitor 10uF Tantalum SMT
C735, C736, C801, C804, C850, C851, C852,
C853, C854, C855, C856, C857, C858, C859,
C860, C861
21230.710.01.1
Capacitor RAD LDS 100uF 50V
HFS
C763
21227.747.01.1
Capacitor RAD LDS 470uF 16V
HF
C764, C765, C842
21171.105.01.1 Capacitor 1uF X7R 0805 C200, C201, C232, C737, C738, C767, C768
21146.310.01.1 Capacitor .01uF 0805 10%
C773, C774, C775, C776, C777, C778, C779,
C780, C781, C782, C783, C784, C785, C833,
C834, C835, C836, C837, C838, C840
21145.000.01.1
Capacitor NPO 5% 100V 33PF-
1206
C231
21143.000.01.1 Capacitor NPO 1500PF 1% 0805 C769, C770, C771
21142.000.01.1 Capacitor NPO 100PF 1% 0805 C772
21140.000.01.1 Capacitor NPO 470PF 1% 0805 C217, C218
20132.100.01.1 Resistor 100K R0805 1% 1/8W R504, R507, R601, R602, R603, R703
20131.499.01.1 Resistor 1/8W 1% 49.9K 0805 R704, R706
20131.249.01.1 Resistor 1% 24.9K 0805 R203, R209, R213, R216
20131.100.01.1 Resistor 10K 0805 R237, R505, R711, R901
20130.845.01.1 Resistor 1/8W 1% 8.45K 0805
R201, R202, R207, R208, R211, R212, R214,
R215
20129.150.01.1 Resistor 1/8W 1% 150 Ω 0805 R616
20128.075.01.1 Resistor 75 Ω 1% 0805 R238, R508, R509
20128.022.01.1 Resistor 22 Ω 1% 0805 R806, R807, R808, R809, R810, R811
24766.000.01.1 IC PLL1707DBQ IC812
12004.408.01.1 Nut Hex STL C2 4-40 X 1/4 HS700
10009.406.01.1 Screw MS SEM P/P 4-40 X 3/8 HS700
