IMPORTANT NOTE: Refer to the unit’s rear panel for your Model Number.
Model Number: Description:
8685 OPTIMOD 8685 audio processor for digital surround transmission channels.
7.1-channel surround processing and three independent 2.0 processors, all
with loudness meters and CBS Loudness Controllers.
Option 1 3G HD-SDI Input/Output Interface Module
Option 2 3G HD-SDI Input/Output Interface Module with Dolby-E Decoder
Option 3 3G HD-SDI Input/Output Interface Module with Dolby-E Encoder
Option 4 3G HD-SDI Input/Output Interface Module with Dolby-E Decoder and Encoder
MANUAL:
Part Number: Description:
8685 Operating Manual
CAUTION:
TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
This symbol, wherever it appears, alerts you to
the presence of uninsulated dangerous voltage
inside the enclosure ⎯ voltage that may be
sufficient to constitute a risk of shock.
This symbol, wherever it appears, alerts you to important
operating and maintenance instructions in the accompa-
nying literature. Read the manual.
In accordance to the WEEE (waste electrical and electronic equipment) direc-
tive of the European Parliament, this product must not be discarded into the
municipal waste stream in any of the Member States. This product may be
sent back to your Orban dealer at end of life where it will be reused or recycled
at no cost to you.
If this product is discarded into an approved municipal WEEE collection site or
turned over to an approved WEEE recycler at end of life, your Orban dealer
must be notified and supplied with model, serial number and the name and
location of site/facility.
Please contact your Orban dealer for further assistance.
www.orban.com
