OPTIMOD SURROUND PROCESSOR INSTALLATION
2-23
SDI Channel 1/2 Output Routing
Lf/Rf, C/LFE, Ls/ Rs, Lb/ Rb, Lst1/Rst1, Lst2/Rst2,Lst3/Rst3, Lst4/Rst4,
Ldm/Rdm, Lst1>MONO, Rst1>MONO, Lst2>MONO, Rst2>MONO,
Lst3>MONO, Rst3>MONO, Lst4>MONO, Rst4>MONO, SDI_1/2; [Dolby-E
option] DE_1/2, DE_3/4, DE_5/6, DE_7/8
SDI Channel 3/4 Output Routing
Lf/Rf, C/LFE, Ls/ Rs, Lb/ Rb, Lst1/Rst1, Lst2/Rst2,Lst3/Rst3, Lst4/Rst4,
Ldm/Rdm, Lst1>MONO, Rst1>MONO, Lst2>MONO, Rst2>MONO,
Lst3>MONO, Rst3>MONO, Lst4>MONO, Rst4>MONO, SDI_3/4; [Dolby-E
option] DE_1/2, DE_3/4, DE_5/6, DE_7/8
SDI Channel 5/6 Output Routing
Lf/Rf, C/LFE, Ls/ Rs, Lb/ Rb, Lst1/Rst1, Lst2/Rst2,Lst3/Rst3, Lst4/Rst4,
Ldm/Rdm, Lst1>MONO, Rst1>MONO, Lst2>MONO, Rst2>MONO,
Lst3>MONO, Rst3>MONO, Lst4>MONO, Rst4>MONO, SDI_5/6; [Dolby-E
option] DE_1/2, DE_3/4, DE_5/6, DE_7/8
SDI Channel 7/8 Output Routing
Lf/Rf, C/LFE, Ls/ Rs, Lb/ Rb, Lst1/Rst1, Lst2/Rst2,Lst3/Rst3, Lst4/Rst4,
Ldm/Rdm, Lst1>MONO, Rst1>MONO, Lst2>MONO, Rst2>MONO,
Lst3>MONO, Rst3>MONO, Lst4>MONO, Rst4>MONO, SDI_7/8; [Dolby-E
option] DE_1/2, DE_3/4, DE_5/6, DE_7/8
Analog Output Routing
Lf/Rf, Lst1/Rst1, Lst2/Rst2, Lst3/Rst3, Lst4/Rst4, Ldm/Rdm, Lf, Rf, C, LFE,
Ls, Rs, Lb, Rb, Lst, Rst, Ldm, Rdm, Lst1, Rst1, Lst2, Rst2, Lst3, Rst3, Lst4,
Rst4, AES_1/2, AES_3/4, AES_5/6, SDI_1/2, SDI_3/4, SDI_5/6, SDI_7/8;
[Dolby-E option] DE_1/2, DE_3/4, DE_5/6, DE_7/8
Analog Headphone Routing
Lf/Rf, Lst1/Rst1, Lst2/Rst2, Lst3/Rst3, Lst4/Rst4, Ldm/Rdm, Lf, Rf, C, LFE,
Ls, Rs, Lb, Rb, Lst, Rst, Ldm, Rdm, Lst1, Rst1, Lst2, Rst2, Lst3, Rst3, Lst4,
Rst4, AES_1/2, AES_3/4, AES_5/6, SDI_1/2, SDI_3/4, SDI_5/6, SDI_7/8;
[Dolby-E option] DE_1/2, DE_3/4, DE_5/6, DE_7/8
Dolby-E Channel 1/2
Output Routing
Lf/Rf, C/LFE, Ls/ Rs, Lb/ Rb, Lst1/Rst1, Lst2/Rst2,Lst3/Rst3, Lst4/Rst4,
Ldm/Rdm, Ldm/Rdm, Lst>MONO, Lst1>MONO, Rst1>MONO,
Lst2>MONO, Rst2>MONO, Lst3>MONO, Rst3>MONO, Lst4>MONO,
Rst4>MONO, SDI_1/2, SDI_3/4, SDI_5/6, SDI_7/8; [Dolby-E option]
DE_1/2
Dolby-E Channel 3/4
Output Routing
Lf/Rf, C/LFE, Ls/ Rs, Lb/ Rb, Lst1/Rst1, Lst2/Rst2,Lst3/Rst3, Lst4/Rst4,
Ldm/Rdm, Ldm/Rdm, Lst>MONO, Lst1>MONO, Rst1>MONO,
Lst2>MONO, Rst2>MONO, Lst3>MONO, Rst3>MONO, Lst4>MONO,
Rst4>MONO, SDI_1/2, SDI_3/4, SDI_5/6, SDI_7/8; [Dolby-E option]
DE_3/4
Dolby-E Channel 5/6
Output Routing
Lf/Rf, C/LFE, Ls/ Rs, Lb/ Rb, Lst1/Rst1, Lst2/Rst2,Lst3/Rst3, Lst4/Rst4,
Ldm/Rdm, Ldm/Rdm, Lst>MONO, Lst1>MONO, Rst1>MONO,
Lst2>MONO, Rst2>MONO, Lst3>MONO, Rst3>MONO, Lst4>MONO,
Rst4>MONO, SDI_1/2, SDI_3/4, SDI_5/6, SDI_7/8; [Dolby-E option]
DE_5/6
Dolby-E Channel 7/8
Output Routing
Lf/Rf, C/LFE, Ls/ Rs, Lb/ Rb, Lst1/Rst1, Lst2/Rst2,Lst3/Rst3, Lst4/Rst4,
Ldm/Rdm, Ldm/Rdm, Lst>MONO, Lst1>MONO, Rst1>MONO,
Lst2>MONO, Rst2>MONO, Lst3>MONO, Rst3>MONO, Lst4>MONO,
Rst4>MONO, SDI_1/2, SDI_3/4, SDI_5/6, SDI_7/8; [Dolby-E option]
DE_7/8
NOTES and ABBREVIATIONS:
DE = Dolby-E; dm = downmix; Lstx = left channel of 2.0 processor x (x =
1…4); Rstx = right channel of 2.0 processor x; MONO = identical signals
appear on channels 1 and 2 of given destination
Table 2-2: Routing Switcher Sources and Destinations
5. Set up routing for the Penteo 2.0Æ5.1 upmixer (optional).
Skip this step if you are not going to use the stand-alone Penteo upmixer.
The routing switcher configuration depends on whether the optional HD-SDI
board is installed and, if so, whether you will be driving the 8685’s surround
processing with the audio embedded on the SDI signal or via the board’s three
AESid inputs.
In all cases, the input applied to the Penteo must be at a 48 kHz sample rate. The
Penteo is not equipped with sample rate converters, so its output sample rate
will be the same as its input sample rate. This will ordinarily be locked to house
sync. For details, see Sample Frequency Synchronization on page 1-14.
