How to use
36
PreparationSafety precautions Help Appendix
There are two methods to operate the motor.
Operating using the operation panel Operating using external signals
The motor can be operated using the operation panel of the driver.
Motor
The motor can be operated using external signals or
the
MEXE02
.
Programmable
controller, etc.
Motor
1. Operating using the operation panel
Press
50 r/min (factory setting)
Press
The motor stops.
AC power ON
1
4
Turn
Changing speed of motor
[example: 50 to 1000 r/min ]
The display blinks.
You can adjust the speed while blinking.
∗
Press
Set
Adjustment
Press
5
Start of motor
The display changes to lighting from blinking, and the speed will be set.
When you start the motor next time, it will rotate at the set speed.
LOCAL
RUN key
STOP key
LOCAL key
MODE key
Setting dial
LOCAL LED
Accelerate
Decelerate
To stop the motor
When the power supply is turned on,
the display shows as follows.
Display: Rotation speed
0 r/min (standstill)
∗
If is displayed, set the "Speed, torque limiting command selection" parameter to "0: Digital setting."
If the rotation speed or the torque limiting is set to the analog setting, an external control device is required to connect to rotate the motor.
The motor rotates.
Rotation direction selection
Press
∗
The gures show the round shaft type.
In the case of the gearhead output shaft, the rotation direction
varies depending on the gear ratio of the gearhead.
The motor rotation
direction changes whenever
the MODE key is pressed.
The LOCAL LED is lit in green.
The operation using the operation panel is set,
and the rotation speed and rotation direction are
alternately continued to show on the display.
Press the LOCAL key.
Press
3
Operation selection
2
Interval of approximately 1 second
Refer to p.48 for details about the
operation panel.
Check the operating manual
of the motor for the rotation
direction of the gearhead
output shaft.
Operating
