How to use
68
PreparationSafety precautions Help Appendix
Waveform monitor
The motor rotation speed or the status of I/O signals can be checked in a waveform format.
Refer to the operating manual of the
MEXE02
for the procedures to operate the applicable products using the
MEXE02
.
z
CH1 to CH4 (analog CH)
The rotation speed or the detected torque (actual torque), etc. can be checked. Using the waveform monitor can check successive
changes.
Monitored items Unit Range selection
Command speed (motor shaft) r/min 100, 200, 500, 1000, 2000, 5000
Actual speed (motor shaft) r/min 100, 200, 500, 1000, 2000, 5000
Main circuit DC voltage V 50, 100, 200, 500
Actual torque % 50, 100, 200
Selection number − 1, 2, 5, 10, 20
External analog setting device V 1.0, 2.0, 5.0, 10.0, 20.0
z
CH5 to CH12 (digital CH)
The ON/OFF status of signals can be checked. There is no setting for range and oset in the digital CH.
Monitored items Monitored items Monitored items Monitored items Monitored items
ALARM-OUT DIR INFO-CFG INFO-PTIME MB-FREE
ALARM-RESET DOUT0 INFO-DRVTMP INFO-RBT MOVE
DIN0 DOUT1 INFO-DRV INFO-SPD REV (RUN/BRAKE)
DIN1 EXT-ERROR INFO-DSLMTD INFO-TRIP SPEED-OUT
DIN2 FWD (START/STOP) INFO-IOTEST INFO-UVOLT STOP-MODE (CW/CCW)
DIN3 H-FREE INFO-LOAD M0 TL
DIN4 HMI INFO-ODO M1 TLC
DIN5 INFO-CLR INFO-OVOLT M2 VA
DIN6 INFO INFO-PCOUNT M3
z
Time scale
The following time scales can be set.
5, 10, 20, 50, 100, 200, 500, 1000, 2000, 5000 [Unit: ms]
3. Teaching, remote operation
A motor can be operated using the
MEXE02
. The motor operation can be checked before connecting to a programmable
controller.
Also, the teaching function of the operation data can be performed.
The ALARM LED on the driver blinks in orange when teaching/remote operation is started.
Note
•
While teaching/remote operation is performed, the motor is operated based on the data set in the teaching data.
•
If the motor is used in a state where the output torque is limited, check the setting of the teaching data before
performing teaching/remote operation.
•
If the operation input signal was ON (active state) when teaching/remote operation is completed, the operation
prohibited information is generated. The operation prohibited information can be cleared by turning the operation
input signal OFF.
