The
MEXE02
is software to set the data required to operate the motor using a PC.
Refer to the operating manual of the
MEXE02
for how to use such as data editing method and others.
This chapter explains details about the
BLE2
Series.
1. Starting
MEXE02
Select the product.
Series: BLE2
Prodcut: BLE2
2. Monitor
Unit information monitor
The device information of the
BLE2
Series can be monitored.
z
How to view the unit information monitor window
Item Description
Driver user name Monitors the name set in the "Driver user name" parameter.
Product name Monitors the model name of the driver.
Ver. Monitors the software version used.
Main power count Monitors the number of times that the main power supply of the driver is turned on.
Main power supply time Monitors the integrated value of the main power supply time of the driver.
Electromagenetic brake Y/N
Yes: This is a driver that the electromagnetic brake can be connected.
No: This is a driver that the electromagnetic brake cannot be connected.
Regeneration resistor connection
Disable: The setting is in a state where the regeneration resistor is not used.
Enable: The setting is in a state where the regeneration resistor is used.
Refer to p.23 for how to use the regeneration resistor.
Driver setting value Monitors the parameter values set in the driver.
Status monitor
The operating status of the
BLE2
Series can be monitored.
z
How to view the status monitor window
Main monitored items Description
Command speed (motor shaft) Monitors the present command speed.
Actual speed (motor shaft) Monitors the present feedback speed.
Command speed (gearhead shaft) Monitors the present command speed as a value converted by the set speed reduction ratio.
Actual speed (gearhead shaft) Monitors the present feedback speed as a value converted by the set speed reduction ratio.
Gear ratio Monitors the gear ratio presently set.
Speed increasing ratio Monitors the speed increasing ratio presently set.
Selection number Monitors the operation data number presently selected.
Load factor
Monitors the present motor output torque as a load factor. The load factor is a value based on the
rated torque being 100%.
Main circuit DC voltage Monitors the present voltage value inside the driver.
External analog setting device
(input voltage)
Monitors the voltage value of the external analog setting device presently input.
Elapsed time from BOOT Monitors the time that has elapsed since the power supply was turned on.
Driver temperature Monitors the present driver temperature.
Odometer Monitors the cumulative rotation amount inside the driver since the driver was started operating.
Tripmeter
Monitors the total rotation amount inside the driver. The value of the tripmeter can be cleared by
executing "Clear tripmeter."
Alarm
Monitors the present alarm status. Details of the alarm generated and the driver status when the
alarm was generated can be checked using the alarm monitor.
Information
Monitors the present information status. Details of the information can be checked using the
information monitor.
Sequence history
Monitors the operation data numbers executed previously (the latest 16 data). "−" is displayed
when the motor is stopped, and the value same as the selection number is displayed during
operation. The sequence history can be cleared by executing "Clear sequence history."
