3-3 Alarm/information setting parameters
A: Update immediately, C: Update after executing conguration or turning on the power again
ID Parameter name Description Setting range
Factory
setting
Update
384 Overload alarm detection time
Sets the detection time of the overload alarm.
200 W or lower: At a time of about 180% load
300 W or higher: At a time of about 150% load
0.1 to 40.0 [s] 30.0 A
414
Prevention of operation at power-on
alarm
If the “Prevention of operation at power-on
alarm” parameter is set to disable, the motor
can be operated by ON-OFF control of the
power supply. Refer to p.62 for details.
0: Disable
1: Enable
1
C
413
Electromagnetic brake function at
alarm
Sets the action of the electromagnetic brake
when an alarm is generated.
0: Lock after coasting to a stop
1: Lock immediately
1
447 INFO auto clear
Sets whether a state of generating information
is automatically cleared when the cause
generated the information was removed.
0: Disable
1: Enable
1
A
416 Driver temperature information
Sets the generation condition of the driver
temperature information.
40 to 85 [°C] 85
418 Speed information
Sets the generation condition of the speed
information.
50 to 5000 [r/min] 5000
422 Load information
Sets the generation condition of the load
information.
10 to 300 [%] 300
425 Overvoltage information
Sets the generation condition of the
overvoltage information.
280 to 440 [V] 435
426 Undervoltage information
Sets the generation condition of the
undervoltage information.
120 to 280 [V] 120
431 Tripmeter information
Sets the generation condition of the tripmeter
information.
0: Disable
1 to 999,999,999 (1=0.1 kRev)
0
432 Odometer information
Sets the generation condition of the odometer
information.
0: Disable
1 to 999,999,999 (1=0.1 kRev)
0
438 Main power supply time information
Sets the generation condition of the main
power supply time information.
0: Disable
1 to 999,999,999 [min]
0
439 Main power supply count information
Sets the generation condition of the main
power supply count information.
0: Disable
1 to 999,999,999 [times]
0
1954
INFO action (Driver temperature
information (INFO-DRVTMP))
Set the INFO output and LED status when
corresponding information is generated.
Only the specied information can be output.
※
The bit output status of each Information is
not changed.
The bit output can be checked using the
internal I/O monitor of the
MEXE02
.
0: INFO action is not applied
• INFO output: OFF
• LED: Unlit
1: INFO action is applied
• INFO output: ON
• LED: Blink
1
1956
INFO action (Overvoltage information
(INFO-OVOLT))
1957
INFO action (Undervoltage
information (INFO-UVOLT))
1959
INFO action (Load information (INFO-
LOAD))
1960
INFO action (Speed information
(INFO-SPD))
1964
INFO action (Operation prohibited
information (INFO-DRV))
1972
INFO action (Tripmeter information
(INFO-TRIP))
1973
INFO action (Odometer information
(INFO-ODO))
1978
INFO action (Main power supply time
information (INFO-PTIME))
1979
INFO action (Main power supply
count information (INFO-PCOUNT))
1980
INFO action (Start operation restricted
mode information (INFO-DSLMTD))
1981
INFO action (I/O test mode
information (INFO-IOTEST))
1982
INFO action (Conguration request
information (INFO-CFG))
1983
INFO action (Power cycling request
information (INFO-RBT))
Note
•
When the product is used in an application of vertical drive such as elevating equipment, set the "Electromagnetic brake
function at alarm" parameter to "1: Lock immediately." Setting to "0 : Lock after coasting to a stop" causes a load to fall.
•
When an alarm of the sensor error is generated, the electromagnetic brake is activated to hold the motor shaft (a
load) regardless of the setting of the "Electromagnetic brake function at alarm" parameter.
