Specications
z
300 W and 400 W
Model
Motor
BLM6300SHP
BLM5300HP
BLM7300HW
BLM6400SHP
BLM5400HP
BLM7400HW
Driver
BLE2D300-C BLE2D400-C BLE2D400-S
Rated output power (Continuous) 300 W 400 W
Power
supply
input
Rated voltage
Single-phase 200-240 VAC
Three-phase 200-240 VAC
Single-phase 200-240 VAC Three-phase 200-240 VAC
Permissible voltage range –15 to +10%
Rated frequency 50/60 Hz
Permissible frequency range ±5%
Rated input current
Single-phase: 3.2 A
Three-phase: 1.8 A
Single-phase: 4.6 A
Three-phase: 2.3 A
Maximum input current
Single-phase: 8.5 A
Three-phase: 6.0 A
Single-phase: 9.9 A
Three-phase: 6.1 A
Rated torque 0.955 N·m 1.27 N·m
Peak torque 1.72 N·m (240 oz-in) [80 to 2000 r/min] 2.28 N·m (320 oz-in) [80 to 2000 r/min]
Rated rotation speed 3000 r/min
Speed control range
80 to 4000 r/min
*
*
There are products which maximum rotation speed is 3600 r/min depending on the type of gearhead.
Check the operating manual of the motor.
2. General specications
Operating
environment
Ambient temperature Driver: 0 to +50 °C [+32 to +122 °F] (non-freezing)
*
Ambient humidity 85% or less (non-condensing)
Altitude Up to 1000 m (3300 ft.) above sea level
Surrounding atmosphere
No corrosive gas or dust. Not exposed to oil. Cannot be used in radioactive materials, magnetic
eld, vacuum or other special environment. (For details about installation location, refer to p.13.)
Vibration
Not subject to continuous vibrations or excessive impact. In conformance with JIS C 60068-2-6
"Sine-wave vibration test method"
Frequency range: 10 to 55 Hz Pulsating amplitude: 0.15 mm (0.006 in.)
Sweep direction: 3 directions (X, Y, Z) Number of sweeps: 20 times
Storage
environment
Shipping
environment
Ambient temperature Driver: –25 to +70 °C [–13 to +158 °F] (non-freezing)
Ambient humidity 85% or less (non-condensing)
Altitude Up to 3000 m (10000 ft.) above sea level
Surrounding atmosphere
No corrosive gas, dust, water or oil. Cannot be used in radioactive materials, magnetic eld,
vacuum or other special environment.
Degree of protection Driver: IP20
*
The conditions of use vary when two or more drivers are installed closely in the horizontal direction. Refer to p.14 for details.
