1. Specications
Values in the rated torque, peak torque, rated rotation speed, and speed control range represent those in a state where the
gearhead is not combined.
Motor model columns in the table below describes part of the motor model name. Refer to the operating manual of the motor
for details about the motor models.
z
30 W and 60 W
Model
Motor
BLM230HP
BLM460SHP
BLM260HP
Driver
BLE2D30-A
BLE2D30-AM
BLE2D30-C
BLE2D30-CM
BLE2D60-A
BLE2D60-AM
BLE2D60-C
BLE2D60-CM
Rated output power
(Continuous)
30 W 60 W
Power
supply
input
Rated voltage Single-phase 100-120 VAC
Single-phase 200-240 VAC
Three-phase 200-240 VAC
Single-phase 100-120 VAC
Single-phase 200-240 VAC
Three-phase 200-240 VAC
Permissible voltage
range
–15 to +10%
Rated frequency 50/60 Hz
Permissible frequency
range
±5%
Rated input current
*2
Single-phase: 1.1 A (1.2 A)
Single-phase: 0.67 A (0.71 A)
Three-phase: 0.39 A (0.40 A)
Single-phase: 1.7 A (1.7 A)
Single-phase: 1.0 A (1.1 A)
Three-phase: 0.61 A (0.61 A)
Maximum input current Single-phase: 3.3 A
Single-phase: 2.2 A
Three-phase: 1.2 A
Single-phase: 5.4 A
Single-phase: 3.5 A
Three-phase: 2.0 A
Rated torque 0.096 N·m (13.6 oz-in) 0.191 N·m (27 oz-in)
Peak torque 0.2 N·m (28 oz-in) [80 to 2000 r/min] 0.4 N·m (56 oz-in) [80 to 2000 r/min]
Rated rotation speed 3000 r/min
Speed control range 80 to 4000 r/min
*1
*1
There are products which maximum rotation speed is 3600 r/min depending on the type of gearhead.
Check the operating manual of the motor.
*2
Values in parentheses ( ) indicate those of drivers for electromagnetic brake motor.
z
120 W and 200 W
Model
Motor
BLM5120HP
BLM6200SHP
BLM5200HP
BLM7200HW
Driver
BLE2D120-A

BLE2D120-AM
BLE2D120-C

BLE2D120-CM
BLE2D200-A
BLE2D200-AM
BLE2D200-C
BLE2D200-CM
Rated output power
(Continuous)
120 W 200 W
Power
supply
input
Rated voltage Single-phase 100-120 VAC
Single-phase 200-240 VAC
Three-phase 200-240 VAC
Single-phase 100-120 VAC
Single-phase 200-240 VAC
Three-phase 200-240 VAC
Permissible voltage
range
–15 to +10%
Rated frequency 50/60 Hz
Permissible frequency
range
±5%
Rated input current
*2
Single-phase: 2.7 A (2.8 A)
Single-phase: 1.7 A (1.7 A)
Three-phase: 1.02 A (1.02 A)
Single-phase: 4.3 A (4.4 A)
Single-phase: 2.4 A (2.5 A)
Three-phase: 1.4 A (1.5 A)
Maximum input current Single-phase: 7.4 A
Single-phase: 4.8 A
Three-phase: 3.3 A
Single-phase: 11.5 A
Single-phase: 6.5 A
Three-phase: 4.3 A
Rated torque 0.382 N·m (54 oz-in) 0.637 N·m (90 oz-in)
Peak torque 0.8 N·m (113 oz-in) [80 to 2000 r/min] 1.15 N·m (163 oz-in) [80 to 2000 r/min]
Rated rotation speed 3000 r/min
Speed control range 80 to 4000 r/min
*1
*1
There are products which maximum rotation speed is 3600 r/min depending on the type of gearhead.
Check the operating manual of the motor.
*2
Values in parentheses ( ) indicate those of drivers for electromagnetic brake motor.
