Oriental motor BLE2D60-A - Operating Using External Signals; Overview; Setting Method of the Rotation Speed; Procedures to Set the Rotation Speed

How to use
37
PreparationSafety precautions Help Appendix
Operating
2. Operating using external signals
2-1 Overview
The motor can be operated by setting up to 16 operation data
and selecting the operation data number externally.
Driver
Programmable
controller, etc.
Motor
Operation
data No.
Item Setting range
Factory
setting
Reference
page
0 to 15
Rotation speed 50 to 4000 r/min 50 37
Torque limiting 0 to 300% 300 41
Acceleration time
0.0 to 15.0 s 0.5 43
Deceleration time
2-2 Setting method of the rotation speed
The rotation speed can be set by the following four methods.
Digital setting Analog setting
Operation panel
MEXE02
External
potentiometer
External DC
voltage
0 to 10 VDC
1 mA or more
External
DC power supply
p.52 p.65 p.38
2-3 Procedures to set the rotation speed
2-3-1 When setting with the operation panel
Example
: Set the rotation speed of the operation data No.0 to 1000 r/min.
1
Turn on the AC power supply
Set (store) the data
Change to 1000 r/mim
2
3
Press twice
Press
4
5
6
Turn
Press
Data No.0
Data number
selection screen
Press
Rotation speed
Operation data selection screen
in the data number
Press
Setting screen of rotation
speed
50 r/min (factory setting)
Rotation speed: 0 r/min
[ To return to the rotation speed display ]
Press
Press
ve times
If the display is not shown as the above steps, check "Setting of operation data" of the operation panel on p.52.
Refer to p.39 for the operating method.
