Warning: The current value within a given situation corresponds to a warning
alert.
Critical: The current value within a given situation corresponds to a critical
alert.
Out-of-Sync: The current value could not be synchronized and is outdated.
Unlicensed: This parameter is invalid/unusable without the proper license.
Unknown: The whole module that handles the parameter is down.
Events: Some relevant parameters are associated to events when they change their
value (Tracked) or when their value enters an alert range (Warning, Critical) or a
smart alert.
Note:
The list of all modules and corresponding parameters together with the
value of their attributes can be found in the WRZ-OS API guide.
4.1.1 Table representation
For each specific feature explained through the user-guide, the following table format will
be employed to describe the corresponding parameters along with their relevant attrib-
utes.
An example is given for the network interface where the same directory has been sep-
arated into two tables to follow the same structure as the web GUI panels. The following
table corresponds to the parameters related to the configuration of the network interface.
Table 4-1:
Configuration parameters of the network interface.
OID Name
Value
Type
Description
1.xxx0.x /net/<iface>/xxx Directory related to the <iface> name where OIDs
follow the given pattern: wr0 → 201x, wr1 → 211x,
..., wr15 → 361x & eth0 → 680x, eth1 → 690x.
0.xxx0.7 DHCP <Bool> Enable/Disable the DHCP IPv4 discovery.
0.xxx0.3 IPv4
Address
<Array> [4
x u8]
IPv4 address of <iface> (format: [0-255].[0-255].[0-255].[0-
255]).
0.xxx0.4 IPv4 Net-
mask
<Array> [4
x u8]
Subnet mask.of <iface> (format: [0-255].[0-255].[0-255].[0-
255]).
0.xxx0.5 IPv4 Gate-
way
<Array> [4
x u8]
Default gateway for <iface> (format: [0-255].[0-255].[0-255].[0-
255]).
The next table corresponds to the parameters that provide information (read-only) about
the corresponding interface:
4.1 Parameters API Introduction
CHAPTER 4 • WR-Z16 User Manual Rev. v3.4
31
