2. FLUIDICS
REF : M18-SM-001 Rev 02
Page 10/68 Copyright© Orphée SA. All Rights Reserved. MYTHIC 18
Diluent prime
Vacuum prime
12- Needle up and syringe up
Rocker move above the RBC bath
Needle outside cleaning with diluent and waste vacuum (valve 3+4)
13- Needle down to the rinsing position
14 Syringe up
Second outside needle cleaning (valve 4+8)
Lysis in the WBC bath (0,3 to 0,5ml) (valve 9)
Bubble to mix the dilution (valve 1)
15 Syringe down
RBC bath drain (valve 2)
16- Needle down to the dilution position
17- Syringe up for the RBC dilution (~1,5ml)
Waste syringe drain (valve 7)
Diluent outside of the needle (valve 4+8)
Diluent inside the needle (valve 5)
Bubble to mix the dilution and diluent to rinse the counting head (valve 6+10+2)
MEASUREMENTS :
18- Syringe down to process the vacuum counting (valve 10)
19- First measurement sequences (valve 10)
20- Syringe up
Diluent back pressure (valve 4+6)
21- Syringe down to perform the vacuum counting (valve 10)
22- Second measurement sequences (valve 10)
DRAIN AND RINSE BATH :
22- Syringe down
Cleaning the apertures (valve 11)
WBC bath drain (valve 1)
RBC bath drain (valve 2)
23- Syringe up
RBC bath rinse diluent (valve 4)
Waste syringe drain (valve 7)
24- Needle up and syringes up for back flush (valve 4+6)
25- Rocker move above the WBC bath
26- Syringe up
WBC bath rinse diluent (valve 4)
Waste syringe drain (valve 7)
NEEDLE BACK AND WASTE DRAIN :
27- Syringe down
Dry the outside of the needle (valve 3)
28- Rocker move in the sampling position
26- Syringe up
Waste syringe drain (valve 7)
30- Needle down in sampling position
The MYTHIC 18 is ready to perform a new analyze.
