Orphee MYTHIC 18 - Manifold Tubing Position

2. FLUIDICS
REF : M18-SM-001 Rev 02
Page 14/68 Copyright© Orphée SA. All Rights Reserved. MYTHIC 18
2.5.2 Manifold tubing position
Each figure corresponds to a tubing number (see the Fluidic diagram section 2.5.1)
Counting manifold
Syringe manifold
Syringe body
