REF : M18-SM-001 Rev 02
6. PARTS LISTE & BLOW UP VIEW
MYTHIC 18 Copyright© Orphée SA. All Rights Reserved. Page 39/68
6.1.2 All spare parts
Mythic 18 Spare Parts Rev 3
Designation Part Number Qty/Pkg Unit
1L Straw 005-1001-06 01 1 UNI
40P Flexible Flat Cable 170-4001-05 210 1 UNI
5/10-20L Adaptator 300-1009-05 1020 1 UNI
70W switching adapter 050-1001-01 70 24 1 UNI
Bottle cap filter 010-2501-06 03 10 UNI
Counting Chambers 005-1001-01 01 1 UNI
Counting Manifold 010-2501-01 03 1 UNI
Counting Valves Cable 005-1001-84 04 1 UNI
Electrovalve 2/2 309-0501-152401 1 UNI
Electrovalve 3/2 309-0501-152402 1 UNI
Electrovalve 3/2 - 1.6mm 309-0501-01 016 1 UNI
Fluidic Door Switch 002-1001-84 06 370 1 UNI
Front cover 005-1001-04 02 1 UNI
Lubriplate DS-ES 410-0502-01 1 UNI
Lyse Spring 005-1001-86 01 1 UNI
Mythic 18 (2 years) spare part kit 002-1001-50 20 02 1 UNI
Mythic 18 CPU Board 205-1001-01 1 UNI
Mythic 18 CPU Board & Preamplifier 002-2001-04 1 UNI
Mythic 18 IHM Board 205-1001-02 1 UNI
Mythic 18 Maintenance Kit 002-1001-50 02 1 UNI
Mythic 18 O-Rings kit 002-1001-50 10 1 UNI
Mythic 18 Preampifier Board 205-1001-03 1 UNI
Mythic 18 Tubings kit 002-1001-50 11 1 UNI
Needle Belt 353-0301-08 120 19 1 UNI
Needle carriage 010-2501-02 02 1 UNI
Needle Motor 005-1001-02 02 1 UNI
Needle Optical Sensor 005-1001-82 880 300 1 UNI
O-ring Ø1.07x1.27 Fluocarbon 80SH 312-0505-107 127 10 UNI
O-ring Ø1.4x1.25 Fluocarbon 80SH 312-0505-140 125 010 10 UNI
O-ring Ø13.1x1.6 Fluocarbon 80SH 312-0505-1310 160 10 UNI
O-ring Ø15.54x2.62 Silicone 60SH 312-0501-1554 262 10 UNI
O-ring Ø18.77x1.78 Silicone 60SH 312-0501-1877 178 10 UNI
O-ring Ø21.89x2.62 Silicone 60SH 312-0501-2189 262 10 UNI
O-ring Ø47.34x1.78 Silicone 60SH 312-0501-4734 178 10 UNI
O-ring Ø5x1 Fluocarbon 80SH 312-0505-500 100 10 UNI
O-ring Ø6.35x1.78 Silicone 60SH 312-0501-635 178 10 UNI
O-ring Ø6.3x2.4 Silicone 60SH 312-0501-630 240 10 UNI
O-ring Ø9.52x1.78 Silicone 60SH 312-0501-952 178 10 UNI
O-Ring spacer 010-2501-03 10 1 UNI
