Orphee MYTHIC 18 - GUI Board; Preamplifier Board; Power Supply Block

REF : M18-SM-001 Rev 02
3. ELECTRICS & ELECTRONICS
MYTHIC 18 Copyright© Orphée SA. All Rights Reserved. Page 17/68
3.2.2 GUI board
3.2.3 Preamplifier board
3.2.4 Power supply block
MYTHIC 18 is supplied with an external power supply block.
- In case of replacement of the main power wire supplied with the MYTHIC 18, the new one
must comply with the local regulation.
- The MYTHIC 18 has been certified with the power supply box provided with the machine.
The use of another external power supply box is not guaranteed. Please contact Orphée.
