6. PARTS LISTE & BLOW UP VIEW

REF : M18-SM-001 Rev 02

6.1.2 O-rings kit

Part Number : 002-1001-50 10

Designation : Mythic 18 O-Rings kit

QTY Rev Part Number Designation

1 312-0501-1554 262 O-ring Ø15.54x2.62 Silicone 60SH

1 312-0501-1877 178 O-ring Ø18.77x1.78 Silicone 60SH

2 312-0501-2189 262 O-ring Ø21.89x2.62 Silicone 60SH

1 312-0501-4734 178 O-ring Ø47.34x1.78 Silicone 60SH

1 312-0501-630 240 O-ring Ø6.3x2.4 Silicone 60SH

1 312-0501-635 178 O-ring Ø6.35x1.78 Silicone 60SH

1 312-0501-952 178 O-ring Ø9.52x1.78 Silicone 60SH

2 312-0505-1310 160 O-ring Ø13.1x1.6 Fluocarbon 80SH

3 312-0505-140 125 010 O-ring Ø1.4x1.25 Fluocarbon 80SH

2 312-0505-500 100 O-ring Ø5x1 Fluocarbon 80SH

6.1.2 Tubing kit

Part Number : 002-1001-50 11

Designation : Mythic 18 Tubing kit

QTY Rev Part Number Designation

1 A 005-1001-90 01 Tubing 1

1 A 005-1001-90 02 Tubing 2

1 A 005-1001-90 03 Tubing 3

1 A 005-1001-90 04 Tubing 4

1 A 005-1001-90 05 Tubing 5

1 A 005-1001-90 06 Tubing 6

1 B 005-1001-90 07 Tubing 7

1 A 005-1001-90 08 Tubing 8

1 B 005-1001-90 09 Tubing 9

1 B 005-1001-90 10 Tubing 10

1 A 005-1001-90 11 Tubing 11

1 A 005-1001-90 12 Tubing 12

1 A 005-1001-90 13 Tubing 13

1 B 005-1001-90 14 Tubing 14

1 A 005-1001-90 15 Tubing 15

1 A 005-1001-90 16 Tubing 16

1 A 005-1001-90 17 Tubing 17

1 A 005-1001-90 18 Tubing 18

1 A 005-1001-90 19 Tubing 19

1 A 005-1001-90 20 Tubing 20

1 B 005-1001-90 21 Tubing 21

1 A 005-1001-90 22 Tubing 22

1 B 005-1001-90 23 Tubing 23 - DILUENT

1 B 005-1001-90 24 Tubing 24 - WASTE

1 A 005-1001-90 25 Tubing 25
