REF : M18-SM-001 Rev 02
9. REPARING
Page 54/68 Copyright© Orphée SA. All Rights Reserved. MYTHIC 18
9. REPAIRING
For all the following operations wear rubber gloves and wash hands with a disinfectant after
completion of work.
Be careful with the edge of the metal sheets after having dismantled of the covers.
9.1 EMERGENCY STOP
In case of mechanical or hydraulic problem, immediately press , the MYTHIC 18 will make a emergency
stop.
- After having identified the problem, it is necessary to perform a Control
cycle.
- For an access to this cycle, press
from the
MAIN MENU, then press
9.2 SAMPLING MODULE
9.2.1 Needle replacement
Perform needle replacement as is describe in the User’s Manual.
9.2.2 Complete rocker module replacement
- Before to replace the complete syringe module drain all the tubing :
x Remove the diluent, lysis and cleaner straw from their bottle
x Perform a PRIME ALL (MAIN MENU / REAGENT / PRIME ALL)
- Switch off the MYTHIC and disconnect the power supply.
- Remove the Lysis and Cleaner bottle from their location
- Remove the upper cover (three screws) from the MYTHIC.
