6. PARTS LISTE & BLOW UP VIEW

REF : M18-SM-001 Rev 02

6. PARTS LIST & BLOW UP VIEW

6.1 PARTS LIST

6.1.2 Two years spare parts kit

Part Number : 002-1001-50 20 02

Designation : Mythic 18 (2 years) spare parts kit

QTY Rev Part Number Designation

2 A 002-1001-50 10 Mythic 18 O-Rings kit

1 A 002-1001-50 11 Mythic 18 Tubings kit

2 A 005-1001-03 03 Piston Ø 22

1 A 010-2501-02 05 Sampling needle

1 A 010-2501-03 01 Piston Ø 6.5 - Syringes module

1 A 010-2501-03 02 Piston Ø 16 - Syringes module

6.1.2 Maintenance kit

Part Number : 002-1001-50 02

Designation : Mythic 18 Maintenance Kit

QTY Rev Part Number Designation

1 A 005-1001-90 016 032 Tygon tubing L=1000mm 1.6x3.2mm

1 A 005-1001-90 020 040 Tygon tubing L=500mm 2x4mm

1 B 005-1001-90 09 Tubing 9

1 B 005-1001-90 10 Tubing 10

4 A 010-2501-06 03 Bottle cap filter

5 153-0101-100 25 Cables Ties

2 312-0505-1310 160 O-ring Ø13.1x1.6 Fluocarbon 80SH

1 312-0505-140 125 010 O-ring Ø1.4x1.25 Fluocarbon 80SH

2 312-0505-500 100 O-ring Ø5x1 Fluocarbon 80SH

0,05 410-0501-01 Silicon M1011 grease

1 700-1101-10 Short Arm TORX T10 Tool

1 700-1101-20 Short Arm TORX T20 Tool
