6. PARTS LISTE & BLOW UP VIEW
REF : M18-SM-001 Rev 02
Page 40/68 Copyright© Orphée SA. All Rights Reserved. MYTHIC 18
Designation Part Number Qty/Pkg Unit
Piston Carriage 010-2501-03 08 1 UNIT
Piston Ø 16 010-2501-03 02 1 UNIT
Piston Ø 22 005-1001-03 03 1 UNIT
Piston Ø 6.5 010-2501-03 01 1 UNIT
Plastic grease SPG35 410-0503-01 1 UNIT
RBC Counting Head 005-1001-01 02 02 1 UNIT
Rinsing head 005-1001-02 04 1 UNIT
Rocker Motor 005-1001-02 03 1 UNIT
Rocker Optical Sensor 005-1001-82 880 200 1 UNIT
Sampling module 005-1001-02 01 1 UNIT
Sampling needle 010-2501-02 05 1 UNIT
Screw CBLX M2 x 10 360-0103-020 100 10 UNIT
Screw CZX M3 x 6 360-0101-030 060 10 UNIT
Screw CZX M3 x 8 360-0101-030 080 10 UNIT
Screw CZX M4 x 20 360-0101-040 200 10 UNIT
Screw CZX M4 x 6 360-0101-040 060 10 UNIT
Screw K 30 x 10 363-0201-030 100 10 UNIT
Screw K 30 x 8 363-0201-030 080 10 UNIT
Screw K 40 x 10 363-0201-040 100 10 UNIT
Screw RLX M3 x 6 360-0102-030 060 10 UNIT
Screw RLX M4 x 8 360-0102-040 080 10 UNIT
Seal plate 010-2501-03 06 1 UNIT
Short Arm TORX T10 Tool 700-1101-10 1 UNIT
Short Arm TORX T20 Tool 700-1101-20 1 UNIT
Silent bloc M4 385-1001-04 30 4 UNIT
Start key Switch 005-1001-84 06 170 1 UNIT
Stepper motor cable 005-1001-80 01 220 1 UNIT
Syringe Body 002-1001-03 05 1 UNIT
Syringe Motor 005-1001-03 10 1 UNIT
Syringe Motor Holder 005-1001-03 07 1 UNIT
Syringe Optical Sensor 005-1001-82 880 250 1 UNIT
Syringe Piston Ø 1.6 005-1001-03 09 1 UNIT
Syringe Valves Cable 005-1001-84 03 1 UNIT
Temperature Sensor 005-1001-85 01 50 1 UNIT
Tubing 23 - DILUENT 005-1001-90 23 1 UNIT
Tubing 24 - WASTE 005-1001-90 24 1 UNIT
Tubing Ground Cable 005-1001-84 07 150 1 UNIT
Tygon tubing 0,8x2,4mm 300-0502-008 024 1000 mm
Tygon tubing 1,3x3mm 300-0502-013 030 1000 mm
Tygon tubing 1,6x3,2mm 300-0502-016 032 5000 mm
Tygon tubing 2x4mm 300-0502-020 040 5000 mm
WBC Counting Head 005-1001-01 02 01 1 UNIT
