CAUTION
Overheating of the hydraulics due to excessive strain
Burns, injuries caused by falling due to changes in functionality and damage to prosthesis com
ponents
►
Do not touch overheated prosthesis components.
►
In case of changes in functionality, stop all activities and allow the overheated prosthesis
components to cool down.
►
In case of changes in functionality, reduce strain on the prosthesis component in order to
allow cooling.
►
In case of overheating or changes in functionality, have the prosthesis component inspected
for damage by a service centre authorised by the manufacturer.
►
Inform the patient.
NOTICE
Mechanical damage to the product
Damage due to change in or loss of functionality
►
Use caution when working with the product.
►
If the product is damaged check it for proper function and readiness for use.
►
In case of changes in or loss of functionality, do not continue using the product (see "Signs
of changes in or loss of functionality during use" in this section).
►
Take suitable measures if required (e.g. repair, replacement, inspection by the manufac
turer's customer service etc.).
►
Inform the patient.
Signs of changes in or loss of functionality during use
Noticeable functional changes may include poor response, incomplete extension, diminished
swing phase control or stance phase stability, abnormal noises, etc.
4 Scope of Delivery
The scope of delivery for the product is shown on page2 (Figure1).
The following single components and accessories are included in the scope of delivery in the spe
cified quantities and are available for reordering as single components ( ), single components
with minimum order quantities ( ) or single-component packs ( ):
7E9 Hip Joint
Fig. No. Quantity Designation Reference number
– –   1 Instructions for Use 647G774
1 1 – 1 Hip Joint –
1 2   1 Support Plate 4G576
1 3   1 Lamination Plate (up to 125 kg) 7Z53=1-M10
1 4   2 Oval Head Screw (up to 125 kg) 501S72=M10x25
1 5   2 Flat Head Screw (up to 125 kg) 501S72=M10x30
1 4   2 Flat Head Screw (up to 100 kg) 501F9=M8x25
1 5   2 Flat Head Screw (up to 100 kg) 501F9=M8x30
1 6   1 Hexagon Screwdriver 710H10=2x3
1 7   1 Lamination Aid 7Z63
– –   1 T40 Bit 709Z11
2 1   1 Lamination Plate (up to 100 kg) 7Z53
2 2   1 Bottom Plate (up to 100 kg) 4G420=S
