Table 11: Main connector pin description
1  Supply+  Power supply +
2  Supply-  Power supply -
3  RS232 Tx  Serial nav data transmit
4  RS232 Rx  Serial nav data receive
5  Digital 5
6  Radio data Tx  Serial radio data transmit
7  Radio data Rx  Serial radio data receive
8  Digital 2
9  CAN+  CAN bus high
10  CAN-  CAN bus low
11  Digital 1  Signal ground
12  RS232 common  Serial nav data common
13  ETX-  Ethernet transmit -
14  ERX-  Ethernet receive -
15  Digital 3
16  RS232 common  Serial radio data common
17  CAN ground  Signal ground
18  Digital ground  Signal ground
19  Digital 4
20  ETX+  Ethernet transmit +
21  ERX+  Ethernet receive +
22  Ground  Ground


Table 12: Auxiliary connector pin description
1  ERX-  Ethernet receive -
2  ETX-  Ethernet transmit -
3  Reserved
4  Reserved
5  ERX+  Ethernet receive +
