60
Oxford Technical Solutions
Figure 21. Source selection for Get improved settings
In the Read configuration from box, select the source for the improved settings. The
options are:
• Read configuration from File. If an NCOM file has been saved to disk, or processed
using the NAVsolve, then this file can be read and the settings extracted from it. Use
this setting if you have an NCOM file. Click Browse… and select the NCOM file
you wish to read the configuration from. Do not use an NCOM file that has been
combined from forward and backwards processing of the inertial data.
• Read configuration from Ethernet. This will get the information that the RT is
currently using and apply it next time the RT starts. Use this setting if the RT is
running, has initialised and has warmed up. Select the correct IP address of the RT
to read the configuration from in the drop-down list. Note: the list will not function
correctly if NAVdisplay or other software is using the RT UDP port unless the OxTS
UDP Server is running
Once the source has been selected, click Next and the software will find which settings
can be obtained from the source. Settings that cannot be obtained will be shown in grey;
this may be because the RT is not calculating these values at present. Figure 22 shows
the Settings page with the parameters available to improve in the configuration.
You may update several parameters at once. Select the settings you want to be updated
and uncheck the ones that you do not want to update.
